Specifications
1.Fully automatic operation2.Best after-sale service
3.ISO9001:2008
4.High quality & energy savings
5.Easy installation
1.Technical Parameter
Aluminum alloy | 1000,3000,8000 series |
Entry thickness | 0.6 max mm |
Dia. of working roll | 200~320 mm |
Width of work roller | 800~2300mm |
Dia. of back up roll | Φ550~850 mm |
Width of back-up roller | 750~2250 mm |
Weight of coil | 30000 max kg |
Foil rough-rolling thickness | 0.05~0.2 mm |
Thickness of foil medium-rolling | 0.1 mm |
Thickness of foil rolling (double sheet) | mm |
Rolling speed | 2000 max m/min |
Exit of Al foil width | 700~2080 mm |
Rolling form | Non-reversing |
Electric control system | SIEMENS OMRON |
2.Advantages:
A.Advanced hydraulic pressure on the thickness of the automatic control system (AGC).
B. Piecewise controlled cooling system .
C. Advanced pre-coated plate filtration system.
D. Automatic and manual controlled CO2 fire extinguishing system.
E. Full digital control and network communication
3.Introduction of Hengzhong Heavy:
Zhengzhou Hengzhong Heavy Machinery Manufacturing Co., Ltd. is an aluminum equipment company, which integrates design, manufacture and installation. Our company has a strong technical force, advanced production capacity and high quality after-sale service team. The products have been appreciated & recognized by the old and new customers.
4.Picture shows:
