China best quality high capacity low price mobile grain dryer
- 20 Set / Sets per Month
- Lianyungang/Shanghai/Qingdao port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Type: | Other, Rotary Drying Equipment, Rotary Drying Equipment | Place of Origin: | Henan, China | ||
Brand Name: | Xinguang, Xinguang | Model Number: | All, Rotary Dryer | Voltage: | 380v |
Power(W): | 2.25-6.25 | Dimension(L*W*H): | All | Weight: | 2500-3900kg, 2500-3900kg |
Certification: | ISO, ISO9001:2008 | Warranty: | 1 year, 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Introduction
5HXG grain dryer Grain Dryer is used to drying material such as wheat, maize, paddy and other grain. The 5HXG series structure is compact. Its feeding, circulation, and discharge combined with a lift. It has characteristics like light weight, covers an area of less. The walk type drying equipment can move the same time with drying material .
2.Working principle
Put the grain into the dryer in batch then circulate orderly by the interaction of electric parts and strural parts. the hot air from the husk burner gets into the mixed-flow drying layer to across and heat the grain under the action of two electric fans. the air flows and takes off the moisture of the grain, then the exhaust gas is excluded out of the machine by the exhaust fan when the moisture reaching to the set value, the machine stops working.
3.Technical Data
Item Type | 5 HXG-102 | 5 HXG-135 | 5 HXG-150 | 5 HXG-300 | |||
Weight(kg) | 2900 | 3000 | 3200 | 7500 | |||
Capacity | Rapeseed | min-max volume(kg) | 7500-10300 | 7500-13450 | 7500-14850 | 12000-30000 | |
Max capacity(kg/h) | 473-1135 | 607-1456 | 675-1620 | 1000-3500 | |||
Corn | min-max volume(kg) | 7500-10450 | 7500-13400 | 7500-16800 | 1200-30000 | ||
Max capacity(kg/h) | 756-1261 | 971-1681 | 1080-1800 | 1000-3400 | |||
Wheat | min-max volume(kg) | 7500-10450 | 7500-13350 | 7500-16800 | 1200-30000 | ||
Max capacity(kg/h) | 315-756 | 405-971 | 450-1080 | 1000-3250 | |||
Paddy | min-max volume(kg) | 6500-8400 | 6500-10850 | 6500-15000 | 9000-27800 | ||
Max capacity(kg/h) | 382-916 | 493-1184 | 548-1315 | 850-2800 | |||
Dimension | Height(mm) | 7330 | 8450 | 9070 | 12180 | ||
Length(mm) | 4228 | ||||||
Width(mm) | 2750 | ||||||
Burner | Max capacity(L/h) | High temperature type:35.5 L/h Low temperature type: 25 L/h | |||||
Heat consumption (KG/ (KG. Water) | Below 5800(below national standard) | ||||||
Fuel | Biomass (branch, rice chaff, straw and so on) coal, oil, gas,natural gas, hot-gas. | ||||||
Power | Conveyor Motor(KW) | 2.25kw(3hp) | |||||
Exhaust air motor(KW) | 3.75kw(5hp) | ||||||
Dirt motor(KW) | 0.25kw(1/3hp) | ||||||
Total | 6.25kw(82/3hp) | ||||||
Performance | Loading time | 47 min | 57 min | 63 min | 69 min | ||
Unloading time | 43 min | 53 min | 58 min | 64 min | |||
Drying rate of commodity grain | Rapeseed/ Wheat/ Paddy | Above 0.6-1.2 | |||||
Corn | Above 1.1-2 | ||||||
Drying rate of seed | Rapeseed | Above 0.2-0.7 |
4.Product pictures
5.Company introduction
Zhengzhou Xinguang Mining Machinery Manufacturing Co., Ltd was founded in the 1980s, now has become a group company which own many branches in China and abroad. As a professional mining machinery manufacturer, we provides complete sets of mine selection machines, sand making equipment, cement making equipment, and compound fertilizer equipment, with a production capacity ranging from five tons to five thousand tons per day.
6.Certificate
We are the largest enterprise which specialized in the production of beneficiation machinery in Zhengzhou. It is China import and export enterprise, China AAA grade quality credit enterprise, ISO9001 international quality certification enterprise and international BV quality and environmental system certification enterprise.
7.FAQ
1. Is FOB the only way to pay?
Of course we accept other kinds of payment, but we need to have a more concrete conversation as the
price change. What’s more, we prefer you pick up the machine in our factory, which will cost you least.
In other words, you call a truck or an agent and get the machine in our factory.
2. About install and training?
We have professionals to install in your factory and train your works until they totally get all skills. We can
also provide video and drawing sheet if you don not want us to install for you. Anything wrong with our
machine, we can provide long distance assistance for you.What’s more, we sincerely invite you to visit our
factory. I am sure we will enjoy great time together.
3. What can we do for you if something wrong with the machine?
First, you tell us the problem and our professionals help you with phone or computer. We will send you
fitting parts free of charge. If you can not solve it, we will send people there to help.
