Industrial and Laboratory Vacuum Drying Oven
Industrial and Laboratory Vacuum Drying Oven Features
1. Adopts originated domestic streamline arc design, the outer is made of cold rolled steel plate, the surface is static lacquered;
2. The working room adopts high quality and imported stainless steel or cold-rolled steel plate with corrosion resistant, durable quality;
3. The air-tightness of the chamber door is adjustable, with a wholly-shaped silicon rubber door sealing loop; so as to guarantee in-chamber high vacuum;
4. Double-layer tempering bulletproof glass door is easy to observe the articles in the working room;
5. The rectangular working room makes full use of effective volume;
6. Micro-computer control and LCD display instrument with functions of high precision on temperature control, over-temperature alarm and automatic cut off;
7. Temperature Controller adopt the international advanced PID adaptive controller,do not need to set internal parameters;
8. Optional function: Equipped with a RS-485 port, which can be connected with computer and recorder, to monitor the working status in real time.
Industrial and Laboratory Vacuum Drying Oven Parameters
| Model | DO-VO30 | DO-VO50 | DO-VO90 | DO-VO210 | |
| Volume | 30L | 50L | 90L | 210L | |
| Working Environment | Temperature: +5 - 45°C | ||||
| Relative Humidity: ≤ 85% RH | |||||
| Atmosphere pressure: 86-106Kpa | |||||
| Voltage | AC220±10V, 50±1HZ | ||||
| Temperature Control Range | RT+10 - 250°C | ||||
| Temperature | Accuracy | 0.1°C | |||
| Fluctuation | ±1°C | ||||
| Controller | PID Microprocessor Control, Light Touch Button, Digital Display | ||||
| Sensor | K Type Thermal couple | ||||
| Timer | 1-9999 min | ||||
| Vacuum | ≤133Pa | ||||
| Material | Inside | Mirror Stainless Steel | |||
| Outside | Cold Rolling Steel Plate with Static Lacquered Surface | ||||
| Product Size (W*L*H cm) | Inside | 300*300*275 | 415*370*345 | 450*450*450 | 560*600*640 |
| Outside | 590*470*470 | 710*510*535 | 615*660*1440 | 720*805*1680 | |
| Power (W) | 450 | 1200 | 1400 | 2500 | |
| Tray | 1 | 2 | 2 | 3 | |
| N.W/G.W(KG) | 35/45 | 50/60 | 150/205 | 200/2 | |
Industrial and Laboratory Vacuum Drying Oven Picture
