Specifications
Hot air drying ovenHeat by Forced Churned-up Hot Air Circle
Digtial and Micro-computer Type
Stainless steel
Hot air drying oven
Model: DO-GA40, DO-GA70, DO-GA140, DO-GA240, DO-GA640
Available Volume: 40 litres, 70 litres, 140 litres, 240 litres, 640 litres
Hot air drying oven Instructions and Principle:
1. The chamber of the forced hot air drying oven is made up of superior stain steel sheet or the mirror-finish stainless steel sheet,and the outside sprayed with plastic powder, double-deckde tempered glass-observation,with handsome appearance, and it is safe and convenient to operate on.
2. The forced hot air drying oven is contrplled by the micro-computer,equipped with temperature setting testing,double digtial display and PID self-setting function.
3. Equip with over-temperature auto-protectino & time setting,undulatory property is small.
4. The forced hot air drying oven is equipped with following alarming function,churned-up hot air circle,low heat age lose,blasting and heating can be separately operated.
5. Forced Hot air circle system is made up of exit fans and suitable fan duct with low noisy, the temperature in the chamber is uniformity.
Hot air drying oven Specifictions and User Manual:
| Model | DO-GA40 | DO-GA70 | DO-GA140 | DO-GA240 | DO-GA640 |
| Volume | 40 Liters | 70 Liters | 140 Liters | 240 Liters | 640 Liters |
| Chamber Size | 350*350*350 mm | 450*350*450 mm | 550*450*550 mm | 600*500*750 mm | 800*800*1000 mm |
| Range of Temperature | 50°C-300°C | 50°C-300°C | 50°C-300°C | 50°C-300°C | 50°C-300°C |
| Timer Range | 0-9999 Minutes | 0-9999 Minutes | 0-9999 Minutes | 0-9999 Minutes | 0-9999 Minutes |
| Temperature Fluctuation | ±1°C | ±1°C | ±1°C | ±1°C | ±1°C |
| Power | 1.0 KW / AC220V 50Hz | 1.5 KW / AC220V 50Hz | 2.0 KW / AC220V 50Hz | 2.5 KW / AC220V 50Hz | 4.5 KW / AC220V 50Hz |
| Over-Temperature Alarm | 5°C | 5°C | 5°C | 5°C | 5°C |
| Product Dimension | 500*560*705 mm | 650*560*805 mm | 750*660*905 mm | 800*710*1105 mm | 1000*1010*1355 mm |
