Z115Y medium air pressure engineering large torque drilling rig for mine
- 50 Set / Sets per Month
- QingDao Port
- T/T
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Condition: | New | Type: | Rotary Drilling Rig | Power Type: | Diesel |
| Place of Origin: | Shandong, China | Brand Name: | LongYe | Model Number: | CTQ-Z115Y |
| Voltage: | 24V | Power(W): | 56kw | Dimension(L*W*H): | 5270*1950*2300 |
| Weight: | 4170kg | Certification: | CE | Warranty: | one year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
superiority:
1. excellent steel quality of products
2. supply wearing parts for free
3.our crawler hydraulic drilling rig suitable formountainous and muddy pavement.
4.the YuChai Brand diesel engine life is very long
5. the pump desigh , can save the maintenance cost
6. The work efficiency is very high .
7. Large hydraulic oil design,also separated controllable, meanwhile guarantee stability during fieldwork.
CTQ-Z115Y-type crawler hydraulic drilling rig, using a new hydraulic technology,with low air consumption, large rotary torque , conveniently move the hole. The drilling rig’s structure is compact. while promoting a retractable sliding shelf compensation, drilling when the sliding frame support on the ground, drilling and good stability. Use Z115Y rig reliable and high efficiency in drilling rock. The drilling speed is low air pressure of 1-2 times the rig is a construction unit to reduce the cost and enhance efficiency .
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock blasting whole drilling.
Bore diamete(mm) | 90-130mm |
Bore depth(m) | 40m |
Walk speed | 0-2.5kw/h |
For rock | F=6-20 |
Air pressure(Mpa) | 0.7-1.6Mpa |
Air consumption(m³/min) | 7-15m³/min |
Once promotion(mm) | 3000mm |
Skid pitch | 100° |
Swinging angle of skid | left and right 70 |
Rotation speed | 0-120r/min |
Host power | 56Kw |
Climb ability | 35° |
Dimension(L*W*H) | 5200*1950*2350(mm) |
For rock | F=6-20 |
Weight | 4170Kg |
About ShanDong LongYe Machinary Co.,Ltd. is specialized in the production of hydraulic presure down-hole drilling rigs,engineering drills and water well drilling which are backbone enterprises.
