CTQ-Z115Y high quality hydraulic rotary drilling rig, using a new hydraulic technology, with low air consumption, large rotary torque ,conveniently move the hole . The drilling rig’s structure is compact while promoting a retractable sliding shelf compensation , drilling when the sliding frame support on the ground, drilling and good stability . Use Z115Y rig reliable and high efficiency in drilling rock . The drilling speed is low air pressure of 1-2 times the rig is a construction unit to reduce the cost and enhance efficiency.
The drilling rig is mainly suitable for open mining,water conservancy, power plants, road building and other Rock blasting
hole drilling.
Bore diamete(mm) |
90-130mm |
Bore depth(m) |
40m |
Walk speed |
0-2.5kw/h |
For rock |
F=6-20 |
Air pressure(Mpa) |
0.7-1.6Mpa |
Air consumption(m³/min) |
7-15m³/min |
Once promotion(mm) |
3000mm |
Skid pitch |
100° |
Swinging angle of skid |
left and right 70 |
Rotation speed |
0-120r/min |
Host power |
56Kw |
Climb ability |
35° |
Dimension(L*W*H) |
5200*1950*2350(mm) |
For rock |
F=6-20 |
Weight |
4170Kg |
About ShanDong LongYe Machinary Co.,Ltd. is specialized in the production of hydraulic presure down-hole drilling rigs, engineering drills and water well drilling which are backbone enterprises.
