Factory Supply Complete Brown Rice Milling Machine

Factory Supply Complete Brown Rice Milling Machine thumbnail-1
Factory Supply Complete Brown Rice Milling Machine photo-1
US$ 0.1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
JIETAIZHINENG
Contact Supplier Request Quote Chat Now
Anhui Jietai Intelligent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Anhui, China
Brand Name JIETAIZHINENG
Model Number JTDM-CCDR2
Production Capacity 1.5~3.0T/H
Voltage AC220V,50HZ, AC220V,50HZ
Power(W) 800~2000
Weight 700kg
Dimension(L*W*H) 1647*1520*1800
Certification CE,ISO9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Factory supply complete brown rice milling machine

1. The Color Sorter uses 2048 high-performance CCD image sensor with resolution up to 0.04mm2, to perceive the tiny color difference of material.
2.The Sorter adopts high quality special industrial lens,its working parameters according to the various materials color requirements, and optimize the optical path design, to ensure the each size has a perfect image on the image sensor.
3.The high speed DSP Digital image processing technology provides the sorter with fast detection and high identification rate.
4.According to the spectra characteristics and identification of characteristics of rice.specifically design flexibility and robustness of both special grain detection algorithm start from the spectra analysis to meet slight color detection to improve robustness, to avoid interference with other factors of material surface.
5.The main control system adopts ARM9 high-end embedded processor.it effectively enhances processor speed and color selection precision.
6.The machine adopts intelligent closed-loop control, industrial data bus line can ensure the reliability of the communication and control system, strong anti-interference ability.
7.Super 10 inch screen for color and black-and-white,more flexible in touch and quick in operation. Many setting modes to meet the demand for the more color sorting algorithm.
8.The professional high speed solenoid valve , with more speed and high frequency, low power consumption and longer service life.
9.Double sides cameras and multiple modes can adapt to different demands. and high stability,high precision and low carryover.
10.Using intelligent temperature and pressure control technology to ensure the machine runs in the best working condition.
11.Auto fault-alarming ,modular structure and easy to maintain.



factory supply complete brown rice milling machine



Model

JTDM-CCDR2

JTDM-CCDR3

JTDM-CCDR4

JTDM-CCDR5

JTDM-CCDR6

Throughput(T/H)

1.5~3

3~8

4~11

6~13

7~15

Channels

160

240

320

400

480

Chutes

2

3

4

5

6

Light Source

Led Light

Led Light

Led Light

Led Light

Led Light

Pixel of Camera

2048

2048

2048

2048

2048

Color Sorting Accuracy

≥99.99%

≥99.99%

≥99.99%

≥99.99%

≥99.99%

Carryover rate

≥10:1

≥10:1

≥10:1

≥10:1

≥10:1

Power(KW)

0.8-2

1.0~2.5

1.2~3.0

1.4~3.5

1.6~4.0

Air pressure(Mpa)

≥0.6

≥0.6

≥0.6

≥0.6

≥0.6

Voltage(v)

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

Air consumption (L/min)

800-1300

1000-1800

1200-2500

1500-3000

1800-3600

Weight(kg)

700

900

1100

1300

1500

Diamension(mm)L*W*H

1674* 1520*1800

1674* 1520*1800

1983*1520*1800

2319*1520*1800

2655*1520*1800

Package

wooden case

wooden case

wooden case

wooden case

wooden case

 Note : The above impurities is around 2% . The Specific parameters will be different based on the raw material and impurities



factory supply complete brown rice milling machinefactory supply complete brown rice milling machine

factory supply complete brown rice milling machine







Packaging & Shipping

Packing Size: 1770*1720*2100mm

Container Load: 5pcs/20FT or add 1 set air compressor ; 11pcs/40GP or add 1 set air compressor

Outer Packing: standard wooden case with protective film inside

factory supply complete brown rice milling machine
Company Information



Anhui Jietai Intelligent Technology Co.,Ltd originated from Thailand in southeast Asia with 20 years experience

 Pass the ISO9001 and international certificate as CE

 Provide OEM and ODM service to overseas customer

 Export to over 10 countries in Southeast Asia, Africa, Middle East and area etc.

 Set up headoffice in Thailand

factory supply complete brown rice milling machine



factory supply complete brown rice milling machine

Our Services
 24hour online service

 one year warranty

 power service team in Thailand

factory supply complete brown rice milling machine



FAQ
Q1: Can I add my logo on the machine?
A: Yes,OEM and ODM are available for us.
    But you should send us the trademark authorization letter.
Q2: How can i get the after - service?
A: We will arrange engineer to install the machine when you perpare for the equipment platform and we have power service team in Thailand southeast.
Q3: Do you have inspection procedures for machine?
A: 100% self-inspection and test before packing
Q4: Could you supply the accessory equipment?
A: Yes, w will supply from cooperate factory if you need.
Q5: Can i have a visit to your factory before the order?
A: Sure, welcome to visit our factory.
    Here is our factory address: Hefei City, Anhui Province, China.
   Our factory is near Shanghai, Suzhou City, We can pick you up in the airport or railway station.
    Hotel booking service is available.



factory supply complete brown rice milling machine
