GNSS survey antenna GS282A
Specifications of GS282A
|
Antenna Specification |
Frequency Range: GPS L1, GLONASS L1, SBAS |
| Impedance: 50 Ohm | |
| Polarization: RHCP | |
| Axial Ratio: ≤ 3 dB | |
| Azimuth Coverage: 360° | |
| Output VSWR: ≤ 2.0 | |
| Gain at Zenith: ≥ 5.5 dBi | |
| Phase Center Error: ± 2 mm | |
|
LNA Specification |
LNA Gain: 40 dB |
| Noise Figure: ≤ 2.0 dB | |
| Output VSWR: ≤ 2.0 | |
| Ripple: ± 2dB | |
| Drain Voltage: 3--18 VDC | |
| Current Consumption: ≤ 45 mA | |
| Group Delay: ≤ 5 ns | |
|
Mechanical Specification |
Dimension: φ147 x 61.8 mm |
| Connector: TNC Female | |
| Weight: 400g | |
|
Environmental Specification |
Operating Temperature: -40°C to +85°C |
| Storage Temperature: -55°C to +85°C | |
| Humidity: 95% Non-Condensing | |
GPS Antenna HX-GS282A | |
1. Using multi feed point design to ensure the superposition of phase center and geometrical center which
could minimize the influence of measurement error to lowest range
2. High gain of the antenna element and the direction map beam width to make sure the receiving satellites
performance of low elevation mask
3. Resistance multipath effects board inside could reduce the measurement error caused by multipath
4. Water proof, shock proof and lightning resistance
Survey antenna is the traditional RTK product standard antenna,can be widely used in land survey,marine
survey,channel survey,seismic monitoring,bridge survey,container opertion,etc.
According to the size, volume of products,using standard packaging.
Via international express (DHL, Fedex, UPS, TNT)are all available.It can be fast for you to transport the goods in your hands.
SunNav Technology Co., Ltd. is a high-tech enterprise that specializes in researching and manufacturing high-precision GNSS motherboard and industrial GNSS products.
Our aim is to provide the high-quality and high-security GNSS products and services.
We have an experienced core technology R&D team, who has been unremitting efforts to research and develop the new GPS and GNSS technologies.
Why choose us?
1.Professional
We are professional GNSS products supplier and have export to more than 10 countries.
2.Productive
Ensures prompt delivery,7 days after we get your receipt.
3.High-quality
Strict and complete quality system guarantees high quality.
4.Service
Your requirement and questions are always our first priority. We focus on every step of the orders, from order confirmation to delivery.
5. Warranty
We guarantee that all GNSS products a year warranty, And to provide comprehensive
after-sales work.
Pls contact me if you have any question.
