Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Brand Name:
SunNav
Model Number:
K501
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Tianjin, China
Brand Name
SunNav
Model Number
K501
Specifacations of K501
| DGPS GNSS Board K501 | |||
| Technical Specifications | Signal Tracking -GPS L1 C/A code, L1/L2 P code -BD-2 B1/B2 | ||
| Performance Specifications | Pseudo Range Accuracy -L1=10cm/L2=10cm -B1=10cm/B2=10cm | ||
| Carrier Phase Accuracy -L1=0.5mm/L2=1mm -B1=0.5mm/B2=0.5mm | |||
| Time Precision: 50ns | |||
| Standalone Positioning Accuracy: <1.5m | |||
| Static Accuracy -Horizontal: ±(2.5 +1×10-6×D)mm -Vertical: ±(5 + 1×10-6×D)mm | |||
| RTK Accuracy -Horizontal: ±(10+0.5×10-6×D)mm -Vertical: ±(20+0.5×10-6×D)mm | |||
| Timing Precision: -GPS 40ns -BD2 50ns -GPS+BD2 50ns | |||
| Measurement precision: 0.1m/s | |||
| Acceleration: 4g | |||
| Overload: 15g | |||
| RTK initialization -RTK initialization time: <10s -Reliability: > 99.9% | |||
| Signal Tracking: -Cold start: <50s -Warm start: <30s -Hot start: <15s -Signal recapture: <2s | |||
| Communications | 3 LV-TTL RS232 Ports -Baud rates up to 115,200 | ||
| Data Format: -NMEA-0183 Support (can customize) -Compass Binary self definition -CMR/CMR+ Support -RTCM2.3 Support -RTCM3.0 Support | |||
| Positioning data update rate -1 Hz, 5 Hz & 10 Hz (depends on installed option) | |||
| Raw data update rate -1 Hz, 5 Hz, 10 Hz & 20 Hz | |||
| Height: no limit | |||
| Speed: no limit | |||
| Physical Characteristics | Size: 46 mm x 71 mm x 13mm | ||
| I/O interface: 20-pin Double male header | |||
| Weight: 26g | |||
| Environmental Characteristics | Operating: -40°C to +85°C | ||
| Storage: -55°C to +95°C | |||
| Humidity: 95% no condensation | |||
| Electrical | Memory: 200MB | ||
| Input Voltage: +3.3V~+6V DC | |||
| Power consuming: 1.0 W | |||
| Radio Frequency Interface | Antenna interface: MCX | ||
| Output Power: +3.3~+6V DC | |||
| Output current: <100mA | |||
| OEM Board K501 (The World first and smallest size GPS+BeiDdou high accuracy RTK GNSS Module) 1.By using the GPS+BeiDou dual system high dynamic processing engine, the positioning accuracy could reach centi-meter 2.The hardware size, interface, data command is capable with other main board 3.K501 could be used on high accuracy land surveying (RTK or Handheld RTK), deformation monitoring system, machine control, integrated system, exploration, high precision agriculture, marine, ports, meteorological, defense, university and institute, high accuracy differential positioning and time service | |||
GNSS Board K501
