Help CenterSunNav R20 Receiver With Inside Hemisphere P307 Gps Oem Board
Related Products
-
Novatel 615 Low Price Gps ModuleNegotiableMOQ: 1 Unit -
SunNav M100T ,use Trimble BD970 Gps ModuleNegotiableMOQ: 1 Unit
-
Novatel OEM 615 Low Price External Gps ModuleNegotiableMOQ: 1 Unit
-
Novatel OEM 615 Low Price Gps Board Gps ModuleNegotiableMOQ: 1 Piece
-
Novatel OEM 615 Low Price GNSS RTK Gps Module Gps Glonass bd GalileoNegotiableMOQ: 1 Piece
High precision GPS OEM board
GPS module Hemisphere P307
gps module, low price gps module, gps tracking module
Signal tracking:
GPS: L1C / A, L2C, L5
GLONASS: L1 C / A, L1P, L2 C / A, L2P
BDS: B1, B2, B3
SBAS: L1 C / A, L5 supports WASS, EGNOS and MSAS
Galileo Galileo GIOVE-A and GIOVE-B are reserved
Accuracy:
Static Accuracy:
Plane accuracy: ± 2.5mm + 1ppm
Elevation accuracy: ± 5mm + 1ppm
RTK Accuracy:
Plane accuracy: ± 1cm + 1ppm
Elevation accuracy: ± 2cm + 1ppm
Code Differential positioning accuracy: 0.25 ~ 0.45m (CEP)
Stand-alone positioning accuracy: 1.5m (CEP)
Speed measurement accuracy: 0.01m / s
Signal tracking:
Cold start time <50s
Warm start time <30s
Hot start time <15s
Signal Recapture: <2s
RTK initialization time: <10s
Initialization Reliability: Typical> 99.9%
ELECTRICAL PARAMETERS
Power consumption: ≤ 3.0W
Power supply voltage: DC 6 ~ 28V, with positive and negative reverse polarity protection
Physical properties
Operating temperature: -40 ℃ ~ +70 ℃
Storage temperature: -45 ℃ ~ +80 ℃
Physical Dimensions: 136mm X 89mm
Weight: 0.7Kg
Protection class: IP67
Impact and Vibration: Anti-2m drop
Indicator: 6 LED indicators
Data interface:
Data output: NMEA-0183, raw data
Data refresh rate: 1 - 50Hz optional
Differential format: RTCM2.3 / 3.0 / 3.1 / 3.2, CMR, RTCA
Communication: radio communication module or GPRS / 3G module (CORS)
Interface: 9 core air connector
Power supply: 2
Baud rate: 9600-115200
Serial port: one
Data link antenna: one
