IGS100 GIS Receiver is based on Windows mobile 6.5 operating system, and it has high-resolution 3.5-inch 480X320 pixel touch screen, with wireless LAN and WAN 2.75G Netcom Communications and data transfer, support for GPS, 320 million autofocus camera and video, support one, two dimensional scanning laser or image reading, support 13.56Mhz RFID reader, Bluetooth 2.0 short distance data transmission.
IGS100 is an ideal, costeffective mobile GIS mapping solutions, in addition to the application of highly integrated functions, it is in strict accordance with industry standard IP54 package designed to meet the concrete floor 1.2 m drop test. And is equipped with a safety 3400mAh lithium polymer battery, to meet the equipment at full capacity 12 hours work!
GNSS Characteristics
Internal antenna: 12 channels
- GPS L1 C/A
- SBAS: WAAS/EGNOS/MSAS
External antenna connector
NMEA-0183 and Sirf Protocol output 1Hz
TTFF:30s
Accuracy Specifications (Horizontal RMS)
Real-time SBAS: 2-5m typical
Processor
ARM architecture Hisilicon 520MHZ
Operating System
Microsoft Windows Mobile 6.5 Professional
Software package includes:
- Internet Explorer®
- Office Mobile
- ActiveSync®
- Transcriber (handwriting recognition)
Communications
Cellular
Built in GSM/GPRS
900/1800 MHz
Bluetooth
Bluetooth 2.0 with EDR
WiFi
Integrated 802.11b / g
Interface
USB
Mini USB interface / charge cradle
GPS
With AGPS function Srif Star III navigation chip
Physical Characteristics
Size 155 mm x70 mm x26 mm
Weight 265g
User Interface
Keyboard
side button
power button
the front of 30 keys keyboard
Display
3.5 inch, HVGA (480X320) TFT high-brightness, touch screen
Touch Panel: Glass analog resistive touch screen
Backlight: LED backlight
Memory
256MB Flash ROM + 128MB SDRAM
Mini SD cards up to 32G
Environmental Characteristics
Operating temperature:-30° to +50°C
Storage temperature:-40° to +60°C
Humidity: 95% non condensing
Waterproof: IP54
Free drop: 1.2 m on concrete
Power Characteristics
3.7V 3400mAH Li-polymer
Battery life: > 12 hrs
Charge time: 4 hours
Removable battery
Electrostatic Discharge:
+ /-15kV air discharge, + /-8kV direct discharge
Multimedia & Sensors
Camera 3M Pixels
Speaker
Microphone
Data collection specifications (Option)
Bar code: one-dimensional laser imaging,
two-dimensional image scanner
RFID 13.56MHz, compatible with 14443/15693 protocol
One-dimensional laser scanner (Option)
Optical resolution: greater than or equal 4mil
Scan Depth: 3.81 cm -60.98 cm
Scan angle: 47 ° ± 3 ° (standard)
Scan speed: 102 ± 12 times per second (bi)
Two graphics scanner (Option)
Optical resolution: greater than or equal 3mil
Scan angle: all the
Scan speed: 300 times
Standard Accessories
StylusHand-strapA/C chargerUSB cable
IGS-100 is based on Microsoft Windows Mobile 6.5 operating system, provides an open platform to support third-party software, As a leader in the field of GIS, it can enable users to install third-party GIS software. Such as ESRI's ArcPad software.
The image of IGS 100 data receiver
According to the size, volume of products,using standard packaging.
Via international express (DHL, Fedex, UPS, TNT)are all available.It can be fast for you to transport the goods in your hands.
SunNav Technology Co., Ltd. is a high-tech enterprise that specializes in researching and manufacturing high-precision GNSS motherboard and industrial GNSS products.
Our aim is to provide the high-quality and high-security GNSS products and services.
We have an experienced core technology R&D team, who has been unremitting efforts to research and develop the new GPS and GNSS technologies.
