US$ 445 - 545
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Brand Name:
SunNav
Model Number:
IGS110
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Tianjin, China
Brand Name
SunNav
Model Number
IGS110
Specifications
1. Field Collector and mechanism controller device2. Receiver Type: 50 Channels
3. Wireless Communication
Specifications of IGS 110
| GNSS Receiver Handheld GIS Data Collector---IGS 110 | |||
| Wireless Communications Available | SBAS (WAAS/ EGNOS/MSAS) <2M ± 0.25m + 1 ppm RMS/ Horizontal | ||
| Radios (all with internal antennas): – Bluetooth™ – Wireless LAN: 802.11b/g – HSDPA/UMTS: Triple band GSM/GPRS/EDGE: Quad band – GPS: high accuracy GPS solutions for GIS application enabling – DGPS: enabled Ntrip embedded thru direct data Communication <1M ± (0.25 m + 1 ppm) RMS/ Horizontal < 2M ± (0.5 m + 1 ppm) RMS/ Vertical | |||
| Highlighted Features | Light weighted Rugged IP 65 handheld | ||
| Processor with 800 MHz | |||
| 256MB RAM | |||
| 2G embedded ROM and supported External 32GB microSD available | |||
| Sub-meter enabled GPS designed | |||
| Drop specifications - 1.2+ Meter drop - Over 1000+ tumbling (50 cm) testing | |||
| Temperature range: - Operating: -20°C~ 60°C - Storage: -40°C ~ 70°C | |||
| Electrical | Processor: Samsung 3SC6410 @800 MHz | ||
| Non Volatile Memory: FLASH 2 GB | |||
| Volatile Memory: SDRAM 256 MB | |||
| Display: 3.5” color LCD TFT Transflective 480 x 640 pixels | |||
| Touch Panel: Analog resistance type | |||
| Keypad: 9 keys, 4 soft Function keys,Camera and Power On/off key | |||
| Visual Indicator: Tricolor LED, Software controlled | |||
| Audible Beeper: 80 dBA SPL @ 10cm, 3.5 kHz 8 to 10 kHz programmable | |||
| Personal Area Network: Bluetooth class II, v2.1 EDR | |||
| Local Area Network: IEEE 802.11b/g 54 Mb/s | |||
| Wide Area Network: UMTS/HSDPA, Triple band, 850/1900/2100MHz GSM/GPRS/EDGE, Quad band 850/900/1800/1900Mhz | |||
| Main Battery: Lithium-Ion Polymer, 3.7V, 2,600 mAh | |||
| USB Charging thru PCs Interface: USB OTG/ RS232 | |||
| Software | Operating System: Windows Mobile 6.5 | ||
| OS Image Loader: Via USB | |||
| Bluetooth Profiles: GAP, SDP, GOEP, DUN, SPP, OPP | |||
| Supported: A2DP, PAN, HID | |||
| Application: Office Mobile, Windows Live Messenger Windows Live Search Plug-in, Remote Desktop Mobile ,OEM PPG Provision | |||
| GPS Performance | Receiver Type: 50 Channels GPS L1 frequency, C/A Code GALILEO Open Service capable1 | ||
| SBAS: WAAS, EGNOS, MSAS, GAGAN | |||
| Time to Fix | Cold Start (Autonomous): 29 s | ||
| Warm Start (Autonomous): 29s | |||
| Hot Start (Autonomous): <1s | |||
| Accuracy for Timepulse RMS 30ns 99% <60 ns Compensated 15ns | |||
| Environmental | Operating Temperature: –20° to +60°C (–4° to +140°F) | ||
| Storage Temperature: –40° to +70°C(–40° to +158°F) (short term storage) | |||
| Humidity: 0% to 90% @50°C for 8 hours non-condensing | |||
| Dust/Fluid Protection: Per IEC 60529 Edition 2.1:2001-02 IP65 8 hours dust, 10 minutes water | |||
| Vibration: Per IEC 60068-2-64 5 to 500Hz, 2.14G,random wave | |||
| Mechanical Shock: Per IEC68-2-27 40G, 11ms, half sine wave | |||
| Drop Resistance: Per IEC 68-2-32 Procedure I 4’ (1.2 m) onto steel surface | |||
| Tumble Resistance: Per IEC 68-2-32 Procedure 2 0.5m, randomly 1000 times on hard surface with 19mm thickness wood backed by 3mm thickness steel | |||
| Physical | Weigh: 400g(with battery) | ||
| Dimension: 140 mm (L) x 82.5mm (W) x 33mm (D) | |||
| Regulatory | Radiated FCC Part 15 Class B, and Part 22/24 | ||
| Conducted Emission NCC LP0002 /PLMN01/ PLMN08 | |||
| Other Regulatory: CCC | |||
| IGS 110 is the next generation of high precision rugged handheld terminal designed specifically for the Mobile GIS required industry. The IGS series equips the capability for both the Field Collector and Mechanism controller device. Its ruggedness and swappable battery designs will withstand the rigors of continuous field works. Communications options are designed available to all necessary working environments. | |||
