SunNav Handheld GPS GIS Data Collector IGS150

Tianjin Jinfeng Surveying Instrument Co., Ltd.
SunNav Handheld GPS GIS Data Collector IGS150 thumbnail-1
SunNav Handheld GPS GIS Data Collector IGS150 thumbnail-2
SunNav Handheld GPS GIS Data Collector IGS150 photo-1
SunNav Handheld GPS GIS Data Collector IGS150 photo-2
US$ 499 - 859 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Gps Receiver
Use:
Hand Held
Screen Size:
3.5 inch
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Receiver
Use Hand Held
Screen Size 3.5 inch
Function Bluetooth-enabled, Photo Viewer, Radio Tuner, Touch Screen
Place of Origin Tianjin, China
Brand Name SUNNAV
Model Number IGS150
Warranty 1 Years
Product Description



IGS150 Handheld GPS

It is windows mobile 6.5 operating system’s mobile GIS, equipped with Bluetooth, GPRS and webcamera.

Robust, streamlined and thin design for hard conditions, easy to operate with one hand.

Provides communication by microphone and video, data transfer, can download the user’s own software.

Professional GPS with high accuracy . Receiving GPS signals with high stability.

Supports download of orbit tracking, with a second advanced application development.

3 megapixel camera, 6 X zoom with autofocus, combined with video function.





GNSS Characteristics

Internal antenna: 20 channels

- GPS L1 C/A

- SBAS: WAAS/EGNOS/MSAS

External antenna connector

NMEA-0183 and Sirf Protocol output 1Hz

TTFF:50s

Accuracy Specifications (Horizontal RMS)

Real-time SBAS: 2-5m typical



Processor

CPU: 624MHZ



Operating System

Microsoft Windows Mobile 6.5 Professional

Software package includes:

- Internet Explorer®

- Office Mobile

- ActiveSync®

- Transcriber (handwriting recognition)



Communications

Cellular

Built in GSM/GPRS

850/900/1800/1900MHz

Bluetooth

Bluetooth 2.0 with EDR

WiFi

Integrated 802.11b / g

Interface

 USB

Mini USB interface V2.0



Multimedia & Sensors

Camera 3M Pixels

Speaker

Microphone



Physical Characteristics



Size



168x88x26 mm



Weight



260g



User Interface



Keyboard



4- function buttons



Display



3.5 inch TFT colours  touch-screen



265k colours, 640 x 480 pixels



Memory



256MB Flash ROM + 128MB SDRAM



Mini SD cards up to 8G







Environmental Characteristics



Operating temperature:



-20° to +60°C



 Storage temperature:



-30° to +70°C



Humidity: 95% non condensing



Waterproof: IP54



Free drop: 1.2 m on concrete







Power Characteristics



3.3V 3000mAH Li-polymer



Battery life: > 8hrs



Charge time: 4 hours



 Removable battery







Standard Accessories



Stylus



Hand-strap



A/C charger



USB cable

 SunNav Handheld GPS GIS data collector IGS150SunNav Handheld GPS GIS data collector IGS150SunNav Handheld GPS GIS data collector IGS150SunNav Handheld GPS GIS data collector IGS150SunNav Handheld GPS GIS data collector IGS150
