Induction Pipe Bending Machine
US$ 50,000 - 850,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
MingHeng
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Induction Pipe Bending MachineUS$ 50,000 - 850,000MOQ: 1 Set -
Elbow Induction Hot Forming MachineUS$ 50,000 - 850,000MOQ: 1 Set
-
Induction Pipe Bending MachineNegotiableMOQ: 1 Set
-
Induction Pipe Bending MachineUS$ 50,000 - 850,000MOQ: 1 Set
-
Elbow Hot Pushing Forming MachineUS$ 50,000 - 800,000MOQ: 1 Set
Condition
New
Place of Origin
Shanghai, China
Brand Name
MingHeng
Model Number
YRT900A-W
Machine Type
Pipe and Tube Bending Machine
Raw Material
Pipe
Material / Metal Processed
Carbon Steel
Power
Hydraulic
Automation
Manual
Extra Services
Heat Treating
Certification
Other, CE, ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Induction pipe Bending Machine could be used for manufacturing SR&LR elbows and 2.5D to 6D bends with size from 18" to 36"The YRT-W series induction elbow and pipe bening machine is not only designed for manufacturing LR&SR elbows, but also for bending pipes with small curvature and large curvature radius of carbon steel, alloy steel and nickel steel.
The machine frame was constructed with high strength steel, it has good features of high stability and reliability, economic space occupation and easy installation, easy operation and strong versatility.
The perfect application of the electric system and hydraulic system to achieve high quality and more efficient.
Machine capacity:
Range of pipe bends: OD108mm to 1200mm (4 inch to 48 inch)
Range of pipe thickness: 5-100mm
Range of bending radius: 2.5D-20D
Range of bending degree: 0-180 degree
Technical Parameter
| YRT250A-W | YRT400A-W | YRT600A-W | YRT800A-W | YRT1200A-W | |
| processing size range (inch) | 4-10'' | 8-16'' | 12-24'' | 16-32'' | 24-48'' |
| max processing thickness (mm) | 20 | 41 | 60 | 60 | 60 |
max pushing power (KN) | 1000 | 1500 | 2000 | 4000 | 4000 |
| stroke of main cylinder (mm) | 2500 | 4500 | 6500 | 8000 | 12000 |
| bending radius (D) | 3-6 | 3-6 | 3-6 | 3-6 | 3-6 |
| overall dimension (M) | 13.5*2.7*1.2 | 16.5*3.5*1.8 | 22*6.5*2.1 | 27*8*2.5 | 37*11*4.2 |
| system pressure (Mpa) | 21 | 21 | 21 | 21 | 21 |
| mechanical power (KW) | 18 | 25 | 38 | 53 | 75 |
| heating power (KW) | 300 | 400 | 500 | 800 | 1250 |
| weight (T) | 15 | 31 | 42 | 80 | 150 |
