Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | MingHeng |
Model Number: | YRT1500A-W | Machine Type: | Pipe and Tube Bending Machine | Raw Material: | Pipe |
Material / Metal Processed: | Other, Carbon steel, alloy steel | Power: | Hydraulic | Automation: | Manual |
Extra Services: | Heat Treating | Certification: | Other, CE, ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Induction pipe Bending Machine could be used for manufacturing SR&LR elbows and 2.5D to 6D bends with size from 18" to 36".The YRT-W series induction elbow and pipe bening machine is not only designed for manufacturing LR&SR elbows, but also for bending pipes with small curvature and large curvature radius of carbon steel, alloy steel and nickel steel.
The machine frame was constructed with high strength steel, it has good features of high stability and reliability, economic space occupation and easy installation, easy operation and strong versatility.
The perfect application of the electric system and hydraulic system to achieve high quality and more efficient.
Machine capacity:
Range of pipe bends: OD108mm to 1200mm (4 inch to 48 inch)
Range of pipe thickness: 5-100mm
Range of bending radius: 2.5D-20D
Range of bending degree: 0-180 degree
Technical Parameter
YRT250A-W | YRT400A-W | YRT600A-W | YRT800A-W | YRT1200A-W | |
processing size range (inch) | 4-10'' | 8-16'' | 12-24'' | 16-32'' | 24-48'' |
max processing thickness (mm) | 20 | 41 | 60 | 60 | 60 |
max pushing power (KN) | 1000 | 1500 | 2000 | 4000 | 4000 |
stroke of main cylinder (mm) | 2500 | 4500 | 6500 | 8000 | 12000 |
bending radius (D) | 3-6 | 3-6 | 3-6 | 3-6 | 3-6 |
overall dimension (M) | 13.5*2.7*1.2 | 16.5*3.5*1.8 | 22*6.5*2.1 | 27*8*2.5 | 37*11*4.2 |
system pressure (Mpa) | 21 | 21 | 21 | 21 | 21 |
mechanical power (KW) | 18 | 25 | 38 | 53 | 75 |
heating power (KW) | 300 | 400 | 500 | 800 | 1250 |
weight (T) | 15 | 31 | 42 | 80 | 150 |
