YWDJ3204B-J Elbow Beveling Machine
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | MINGHENG | Model Number | YWDJ3204B-J | |
| Voltage | 380-440 | Rated Power | 12KW | |
| Dimension(L*W*H) | 1750*1750*1900mm | Weight | 3100KGS | |
| Certification | ISO and CE | Warranty | 24 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
YWDJ3204B-J Elbow angular beveling machine
1. YWDJ3204B-J elbow angular beveling machine has the features of unique design, compact structure and convenient to operate.
2. It could bevel the end of elbows according to different international standard (ANSI B16.9, ANSI B16.28, DIN2605, JIS, GOST, SMS, 3A, ISO, etc).
3. This model could bevel the elbows ranging from 1/2" to 4" with max thickness up to Sch80 seperatedly.
4. The feed lock device and effective cutting are controlled by hydraulic pressure. The machines are fit for the batch production.
5. There are three cutters for each clamp disk, they serve for different ranges of work and can work at the same time to ensure the effective cutting and fully satisfy the stable requirements of the guide track under the status of strong cutting. Using the hydraulic control system, its cutting speed can be adjusted randomly by the size and the thickness of the caliber.
| Parameter Projects | Units | Parameter sets |
| Processing Size Range | Inch | 1/2’’—4’’ |
Max Processing Thickness | Sch | Sch80 |
| Spindle Moving Type | Hydraulic Steepless Speed Control | |
| System Pressure | Mpa | 7 |
| Outlook Size | M | 1.75*1.75*1.8 |
| General Power | KW | 12 |
| Weight | T | 3.1 |
'
