ZDSS-256 Build By Laying Bricks or Stones Wall Brick Shrinkage Dilatometer

ZDSS-256 Build By Laying Bricks or Stones Wall Brick Shrinkage Dilatometer

The device according to GB / T2542-2012 "Test methods for wall bricks" standard design, the upper and lower probe uses 90 ° conical recess. Easy to use, high accuracy, fast, clear reading and so on.

This product is suitable for masonry brick production plants, research institutes, universities, construction engineering departments and other units for detecting the contraction and expansion deformation of sintered common brick, fly ash brick up brick.

Mainly by: base, sample holder, meter frame, on the probe, the fastening screws under the probe, dial indicator, par, try body fixing screws, chassis adjustment screws and other components.

  1,Dial indicator measuring range: 0 ~ 10mm; Min. scale value: 0.01mm;
  2,Standard rod length: (256 ± 0.02) mm; Par measured Heading surface radius: SR = 2.25mm;
  3,Measuring range: 251mm ~ 261mm
