Specification for Semi automatic tin can welder
Usage: It's used for tin can body seam welding. Such as, chemical cans, paint cans etc.
Main Technical Parameters:
| Model | GT-FH18-90-II |
| Welding Speed | 6-18m/min |
| Production Capacity | 20 - 40 cans/min |
| Range of Can Diameter | 220mm - 290mm |
| Range of Can Height | 200mm - 420mm |
| Applicable Materials | Tinplate, Steel-based |
| Applicable Materials Thickness | 0.22 - 0.45mm |
| Overlap | 0.8mm 1.0mm 1.2mm |
| Welding Point Distance | 0.5-0.8mm |
| Applicable Copper Wire Diameter | 1.38mm 1.5mm |
| Cooling Water | 0.4-0.5Mpa, ≤20°C, 7L/min |
| Power | 380V, 50Hz, 18KW |
| Weight | 1200kg |
| Dimensions | 1200*1100*1800mm |
Machine features:
1), PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2), Low voltage apparatus are produced by SCHNEIDER.
3), IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4), OMRON is our sensor supplier.
5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan
Machine Picture:
Sample cans the machine can make:
Delivery time: 60 working days
Package: plywood case
Our products' warranty is 1 year!
If there is any quality problem with our machine during the warranty period, we will offer free parts for customer for fix the machine.
Jiujiang Excellent Packaging Machinery Co., Ltd. is located in Jiujiang City in Jiangxi Province and is specialized in manufacturing various tin can making machine,soap making machine,automatic tin can producton line and semi-automatic tin can production line.
With an experienced and professional team, we have exported our products to many countries and regions all over the world. Our products enjoy a good reputation among our customers.
We welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.
At the same standard lever of machines quality,we think if the price is suitable for both of us ,we can come to an agreement and copperation.
Any question or interest, please feel free to contact us!
Contact: Maria
Skype: xiaoyaochana
Mobile/Whatsapp:86-18607020509
Send Inquiry to This Supplier
