firewood briquette machine
1 Introduction of firewood briquette machine
This Wood briquettes extruder also called biomass briquette machine and sawdust briquette making machine, is used to make sawdust into halfstick. It is equipped with the autocontrolling heating system. The byproduct of this machine can be used to heat boiler, fireplace, etc for warm in house. Using the inherent characteristics of wood raw materials, through the screw extrusion, high temperature, high pressure, the wood raw material to make microfiber lignin plastics combine to form a fuel rod. It is the main equipment to make stick solid fuel with such wood material as bits of wood, rice shell or peanuts shell, etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature. During this process, no need to use binder and noxious chemical.
2 Detailed parameters of equipment for the produc fuel briquette
Model | MF-50 | MF-80 |
Output (kg/h) |
180-210 |
340-360kg |
Motor Power (kw) |
15 kw |
22kw |
Electric heater (kw) |
2kw×3pcs |
2kw×3pcs |
Weight(kg) |
700 kg |
1100kg |
Overall dimension(mm) | 1780*750*1290 | 1960*880*1620 |
Size of finished products |
Diameter: |
Diameter: |
3Raw material
Sawdust, rice husks, seed shells, walnut shell, twigs, bark, sediment, vinegar residue, furfural residue, wood chips and various crop stalks are all appropriate materials for briquetting production. Two requirements for raw materials: 1. is size requirement (particle size less than 1cm) 2. is moisture content requirement (below 12%).
6Final products
4 Pre-sale service, Installation and After sales service:
The Pre-sale service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process or a production line. We can advise you on the right solution for the most cost-efficient briquetting.
We can guide you to install the products or directly send our engineer in your country for the installation.
In the after sales service, Henan Machine Co.,Ltd. has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.
8Overview of our factory:
