charcoal and coal briquette press machine
1 General Description of charcoal and coal briquette press machine
Our coal briquettes extruder use the application of the principle of the spiral extrusion , which make it become a certain intensity round or hexagon, triangle, ect charcoal/coal rods by working for the powered coal/charcoal mixed with binder.It is widely used in chemical industry ,metallurgy and ceramic industry , which is the ideal equipments of enterprise specialized in efficient production and reducing consumption.
2 Working principle of charcoal and coal briquette press machine
Our briquettes extruder feed the ratio and retting coal powder mixture into a nitrogentreated barrel by the extrusion of principle , which will compress into section for round, hexagon form or other shape.The final coal/charcoal rods have a certain mechanical strength by formed in this equipments .
3 Outstanding Features of charcoal and coal briquette press machine
1.big incoming lathe screw constant and faster material processing rate and energy saving !
2.Rigid connection is used between the shaft block and cylinder. The machine Φhave a stable working performance better than ever.
3.Hydraulic coupler drive is used . So the machine is smooth in operation and have small noise, Also have the function of overload protection.
4.Custom-made services are provided.
4 Quality Guarantee Terms OF charcoa and coal briquette press machine
Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.
5 Detailed parameters of charcoal and coal briquette press machine
Model |
MBJ140 |
MBJ180 |
MBJ300 |
MBJ400 |
Capacity |
1-2T/H for coal; 0.5-1T/H for charcoal |
2-3T/H for coal; 1-1.5T/H for charcoal |
3-5T/H for coal; 1.5-2.5T/H for charcoal |
6-10T/H for coal; 3.0-5.0T/H for charcoal |
|
Diameter of mould |
20-40mm |
20-60mm |
20-80mm |
20-80mm |
Main shaft speed |
46-60r/min |
39-60r/min |
35-60r/min |
35-60r/min |
|
Number of Spiral Blades
|
4 |
4 |
4 |
4 |
Motor |
Y160m-4 11KW Y160L-4 15KW |
Y180m-4 18.5KW Y180L-4 22KW |
Y225s-4 37KW Y225m-4 45KW |
Y315m-4 160KW |
Reducer |
ZQ350 |
ZQ400 |
ZQ650-750 |
ZQ850 |
Bearing |
7511,211,210,1305 |
7614,314,313,1206 |
32320,320,319,1207 |
32322,322,321 |
Note |
Spindle speed is the lowest speed, according to the current size and load weight, increase the level of appropriate yield
|
|||
