Mechanical/Hydraulic Energy Saving Olive charcoal briquette machine
Description of Olive charcoal briquette machine
The Olive charcoal briquette machine is designed according to the characteristics of all kinds of industry raw materials, mainly used in pulverized coal molding, dry powder molding, charcoal powder molding, coke powder molding, etc.The Olive charcoal making machine have advanced technology, reliable quality, multi-usage, strong pressure, suitable for large, medium and small enterprises to establish a team with a scale of production of production line. According to your raw material and final sample shape and size, our factory has developed a series of olive briquette machine for your reference.
At the beginning, there are two rollers of this briquette machine. Recenely years, to improve roller pressure and increase briquettes hardness, we designed 4 rollers briquette machine(hydraulic type), which adopts molding twice strategy. So the finished briquettes have high hardness, even down from 3 meters height, no shattered.
Working principle: this series briquette machine pass power materials onto two pressure rollers through the reducer, then two rollers rotate to two sides, so materials naturally enter the roller molds, with the rollers rotation. When the material reach the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Types we have as follows, if you can share me your raw materials and capacity demands, I will suggest suitable type for you.
Main parameter of Olive charcoal briquette machine
Type |
Capacity (t/h) |
Roll Diameter (mm) |
Pressure(t) |
Roll Speed (r/min) |
Power (kw) |
Reducer |
MC-290 |
1.5-2 |
290 |
18-20 |
15-17 |
5.5 |
ZQ290 |
MC -360 |
2.5-3.5 |
360 |
20 |
15-17 |
7.5 |
ZQ360 |
MC -400 |
4-5 |
400 |
22 |
15-17 |
11 |
ZQ400 |
MC-500(1) |
6-8 |
370 |
24 |
15 |
15 |
ZQ500 |
MC-500(2) |
8-10 |
500 |
25 |
15 |
22 |
ZQ650 |
MC -650 |
10-15 |
650 |
30 |
15 |
30 |
ZQ650 |
MC -750 |
15-20 |
750 |
34 |
13 |
30 |
ZQ750 |
MC -850 |
25-30 |
850 |
54 |
13 |
37-45 |
ZQ850 |
MC 1000(1) |
35-40 |
1000 |
60 |
12 |
45-75 |
ZSY-355 |
MC 1000(2) |
35-45 |
1000 |
77-240 |
10 |
75-90 |
ZSY-400 |
|
Shape and size of final briquettes: square, ball egg-shaped, round, oval, and column, strip-type, elliptic type, pillow type and other special shapes by customizing the matching molds. Usurally 20-60mm. | ||||||
Specifications
Olive charcoal briquette machine
1 .Reasonable price
2. Reliable quality
3. On time shipment
4. With 30 years' development
The molds
Characteristics of Olive charcoal briquette machine
1.It can be used to different charcoal after carbonized, such as: coconut shell charcoal, peanut shell charcoal, sawdust charcoal, etc.
2.The finished product of Olive charcoal briquette machine has a high density, high hardness.
3 Saving energy in burning, and .the Olive charcoal making machine is convenient to transport
4. The shape is various, can be round, hollow round, oval, pillow, egg, square, rectangle, etc.
5. Special Installation structure makes the change and repair of parts convenient
6. Our engineers can design Olive charcoal machine by your requirements
Shape and size of final product
The whole Olive charcoal ball press machine production line
Raw materials--> Charcoal crusher --> Wheel mixer and liquid mixer --> Feeder --> Charcoal briquette machine --> Dryer.
Our Services
Quality guarantee is one year. Spare parts we supply at factory cost lifetime.
We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video asap, if big problem we will send engineer to working site within 1 week.
