Large output and low consumption charcoal stick extruder machine
Introduction of Wood briquettes extruder machine/biomass briquette machine
This Wood briquettes extruder also called biomass briquette machine and sawdust briquette making machine, is used to make sawdust into half-charcoal-stick. It is equipped with the auto-controlling heating system. The byproduct of this machine can be used to heat boiler, fireplace, etc for warm in house. Using the inherent characteristics of wood raw materials, through the screw extrusion, high temperature, high pressure, the wood raw material to make micro-fiber lignin plastics combine to form a fuel rod. It is the main equipment to make stick solid fuel with such wood material as bits of wood, rice shell or peanuts shell, etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature. During this process, no need to use binder and noxious chemical.
Suitable Raw materials are as followings
Any types of Agro-forestry waste and forest waste can be used for make briquettes Such as maize stalks, soybean stalks, broomcorn stalks, cotton stalks, rape stalks, peanut plants, sunflower stalks, bamboo sawdust, bagasse , wood chips, rice husk, coffee husk, coir pith, jute sticks, groundnut shells, Bamboo, wood, straw dust, Mustard stalk and cotton stalks ,nutshell, coconut shell ,etc( biomass straw coal briquette machine)
Working Priciple of Wood briquettes extruder machine/biomass briquette machine
Briquetting is a process that biomass is compressed under high pressure and high temperature.The lignin content that occurs naturally in biomass is liberated under high pressure and temperature. Lignin serves as the glue in the briquetting process, thus binding, compressing the biomass to form into high density briquettes.During this process, no binder needs to be used. So the output briquette is a type of clean and green fuel that is ideal for use in furnaces, boilers and open fires. The density of the briquettes is 900-1400kg/m2.
temperature, high pressure, the wood raw material to make micro-fiber lignin plastics combine to form a fuel rod. It is the main equipment to make stick solid fuel with such wood material as bits of wood, rice shell or peanuts shell, etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature. During this process, no need to use binder and noxious chemical.
Advantages of Rice husk briquette machine
1.The main parts of Rice husk briquetting machine adopt wear-resistant materials, prolong the service life than the old type.
2.The briquettes shape and size can be adjusted by yourself, you can also carbonize them into charcoal briquettes, which are flammable and with high calorific value.
3.Our Rice husk extruder machine with higher capacity and lower energy consumption.
4.This series of briquette machine is a new type of wood briquette machine, the finished products are more solid.
5.Reasonable design, reliable quality, simple structure, energy saving, environmental protect, easy operation, convenient maintain.
6.Electrical heating function: Automatic electric heating device can adjust the humidity of materials, can solve the difficulty of no-blocking, no-forming.
temperature, high pressure, the wood raw material to make micro-fiber lignin plastics combine to form a fuel rod. It is the main equipment to make stick solid fuel with such wood material as bits of wood, rice shell or peanuts shell, etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature. During this process, no need to use binder and noxious chemical.
The process for producing wood charcoal briquette as follow
1. Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass muaterial without any additive
4. Carbonized the briquette stick
Main Spare parts for biomass coal briquette machine
Production line for bio coal briquetting machine
The technical parameters of bio wood sawdust charcoal machine for BBQ
Show you more pictures for your reference
Workshop of Bio coal briquette making machine
Appendage
Apart from the wood sawdust charcoal machine for BBQ, other related machine such as feader, grinder, crusher, conveyor and dryer are also available in our factory, it means we can offer a whole product line. In addition, we can help you with the installation.( biomass straw coal briquette machine)
Pre-sale service, Installation and After-sales service
The Pre-sales service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process? Or a production line of complete plant. Henan MeShen Machine Manufacturing&Trading Co.,Ltd.can advise you on the right solution for the most cost-efficient briquetting.
We can guide you to install the products or directly send our engineer in your country for the
installation.
In the after-sales service, Henan MeShen Machine Manufacturing&Trading Co.,Ltd. has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts.Spare and wear parts are always close to you.
Contact Information
If there is anything i can do for you, pls feel free to contact me.Lanlan is always at your service.
Your Success Is Our Business! Hope to have the honor to cooperate with you in the bright future.
