1.Welcome to our company
ShangQiu Da Yi Black Waste Oil Distillation Machine, Waste Oil to Base Oil
The history of waste lubricating oil regeneration technology is about several decades since 1970s and 1980s
in China. It encounters many difficulties and opportunities and the development experienced up and down, but
it made a lot of progress.
1. Why Recycle Used Oil?
Did you know that used engine oil never wears out? It just gets dirty and can be recycled, cleaned, and used again. Recycling used engine oil conserves a natural resource (oil) and is good for the environment too! engine oil poured onto the ground or into storm drains, or tossed into trash cans (even in a sealed container) can contaminate and pollute the soil, groundwater, streams, and rivers. Recycling your used engine oil reduces this pollution threat. When you take your used oil to recycle, you are protecting the environment, conserving a valuable resource, and getting paid for it. That's a winning combination!
Waste motor oil recycling machine is particularly suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil and used hydraulic oil, other used machinery’s lubrication oil. ZSY series are able to effectively remove colloid, oxid, acid, pitch, particles, impurities, water, gas in the used oil. Specially, it can restore the color of used oil and remove the scent rapidly.
Parameters
Parameter name | unit | Parameter | Note |
Treating capacity | Ton/per day(24h) | 7-30 | As required |
Recovery rate |
| 80%-85% | None or tiny water content |
color | International color card | 1.5-2 |
|
Processing feature |
| continuous |
|
Water content |
| Qualified for use | See the oil standard |
Flash point |
| Qualified for use | See the report |
Oil viscosity |
| Qualified for use | See the report |
2.3D Work flow chat of Waste Diesel Recycling Distillation Plant
1.Safety:
Unique technology for 100% guarantee of no fire and explosion accident besides normal measurement
for safety such as safety valve, alarm system, etc.
2.Technology:
We have already obtained the international PCT(Patent Cooperation Treaty) with application number of PCT/CN2010/080573 for Continuous Pyrolysis
Method.
3. Heating method: adopt the latest heating method---take the advantages of both direct heating and indirect heating which brings the following profits:
3.1 Fuel: it saves 20% fuel. Take coal for example, we will save around 100KGS per day. It means you can
save 20 USD per day
3.2 Depreciation: We only need to change the front part of the reactor by using this heating method. It will
cost us around USD20000.00 for changing the whole reactor, while it will only cost us around USD4000.00
for changing the front part of the reactor.
Quality: Besides the normal quality control measurement, we make every part of the machine with special
process card which is designed exactly and strictly according to the ISO14001/9001
Service: we have a professional service staff especially responsible for your running plant besides our sales
manager and the technician.
Serial No. | Items | Contents | |
1 | Equipment type | JL-1 type | JL-2 type |
2 | Raw material | Raw oil Waste engine oil Waste plastic oil Waste rubber oil | Raw oil Waste engine oil Waste plastic oil Waste rubber oil |
3 | Structural form | Vertical band tower | Vertical band tower |
4 | 24-hour disposal amount (no less than) | 6 tons raw material | 10 tons raw material |
5 | 24-hour oil yield (no less than) | 70%-80% | 70%-80% |
6 | Operating pressure | Normal/ Negative pressure | Normal/ Negative pressure |
7 | Power | 20.0kw | 20.0kw |
8 | Mode of cooling | Water cooling | Water cooling |
9 | Consumption of cooling water (T/h) | 9 | 9 |
10 | Heating mode | Hot air | Hot air |
11 | Mounting means | Having base | Having base |
12 | Noise dB(A) | ≤85 | ≤80 |
13 | Heating mode | Hot air | Hot air |
14 | Working form | Intermittent operation | Intermittent operation |
15 | Production period | 20 days | 20 days |
3 .Technical Parameter For Waste Diesel Recycling Distillation Plant
Distillation reactor
Type | Technical parameter | ||||
Steel thickness(mm) | daily disposal(T) | daily power(°C) | daily water(m3) | daily coal(kg) | |
8m3/5T | 12 | 5 | 80 | 0.5 | 500-600 |
12m3/8T | 12 | 8 | 120 | 0.8 | 700-900 |
15m3/10T | 16 | 10 | 180 | 1.5 | 1200-1400 |
30m3/20T | 16 | 20 | 280 | 2.5 | 1500-1600 |
4.Main specification Of Waste Diesel Recycling Distillation Plant
Model | Reactor material | Capacity | Container |
DYZL-05 | 316L stainless steel | 3-5tons | 2*40HQ |
DYZL-10 | 316L stainless steel | 6-10tons | 2*40HQ |
DYZL-15 | 316L stainless steel | 10-15tons | 2*40HQ |
DYZL-20 | 316L stainless steel | 15-20tons | 3*40HQ |
DYZL-25 | 316L stainless steel | 20-25tons | 3*40HQ |
DYZL-30 | 316L stainless steel | 25-30tons | 4*40HQ |
5. Waste Diesel Recycling Distillation Plant Features
1.This continuous oil distillaiton plant can working continuous non-stop for about 30 Days
2.The whole system have pre-heating system, this system use exhaust gas (produced by coal or wood burining to heat distillaiton plant )to heating raw oil before raw oil go into distillaiton reactor. This preaheating sytem can save fuel in great degree and saving heating time .
3.This continuous oil distillaiton plant is environmental protection.
The plant have advance dedust and desulfer system ,wich can keep the smoke go into sky non-polution.
