Major parts
1. Pre-treatment device for raw materials
2. Rapid feeder
3. Reactor
4. Automatic slaging system with characteristics of safety and environmental protection
5. Whirlwind dedusting device with oil steam
6. Rapid condensation system
7. Exhaust purification, recycle and combustion system
8. Heat source supply system
9. Environmental protection and exhaust system for heat source
10. Central electric control system
Feature of our plants:
1.Environmental protection equipment: The complete set of unit produces
no smoke and no smell
2. High efficiency and good performance: the output capacity of pure raw
is more than 80% . net oil yield over more than 40%
3. The design of unit is reasonable and advanced :
Specification | Capacity | Raw material | Working time (hrs) | Shipped by |
DYLY-2200-6000 | 5Ton | Waste tyres | 12 | 2*40HQ |
DYLY-2600-6000 | 8Ton | Cables | 15 | 1*40HQ+1*40FR |
DYLY-2600-6600 | 10Ton | Plastics | 18 | 1*40HQ+1*40FR |
DYLY-2800-6000 | 10Ton | Rubber | 18 | 1*40HQ+1*40FR |
DYLY-2800-6600 | 12Ton | Oil sludge | 20 | 1*40HQ+1*40FR |
Plastic oil parameter | ||
Density | g/cm3 | 0.83-0.87 |
Freezing Point | oC | 10 |
flash point | oC | 40 |
Kinematic viscosity | mPa.s | 8 |
Combustion value | kJ/kg | 9500 |
Tire oil parameter | |
Item | Tire Oil |
Density g/cm3 | 0.90-0.92 |
Freezing Point oC | -10 |
flash point oC | 50 |
Kinematic viscosity mPa.s | 6 |
Combustion valuekJ/kg | 10500 |
Final product and usage
output | usage |
crude oil(45%-55%) | Burn as fuel oil : power plant factory Cement factory Boiler factory and so on
Refine to diesel : Low speed engine like digging machine road roller loading machine and so on |
carbon black(30%-35%) | Make carbon black bars through carbon black pellet machine as fuel
grinding to Increase the mesh of carbon black to make new tyre ,painting and so on |
steel wire(10%) | The steel wire from waste tyre can be re-sale to steel factory |
combustible gas(5%) | recycled to heat the reactor as fuel.save energy |
