Specifications
Microwave Tunnel Commercial Food Dryer1.Industrial stainless steel
2.For fruit and vegetable,meet
3.By PLC.
Large Handling New Technology Microwave Tunnel Commercial Food Dryer
1. Brief Description of Microwave Tunnel Dryer:
Microwave tunnel dryer is a such dryer which is used of microwave to reduce the raw material. Unlike other external heating drying, microwave tunnel dryer can dry the raw material from internal and external at the same time. Using this method, microwave tunnel dryer can save drying time and avoid the raw material becoming metamorphism or coking at the overheat environment. The drying effect is very good, especially for the heat sensitive food.
2. The Working Principles of Microwave Tunnel Dryer:
Microwave tunnel dryer fits for application of microwave in scope of packaged food, bottled food, local products, cooked food, spices, dried beef, duck, chicken, fish products etc. Microwave does function on sterilization and preservation to keep its flesh, flavor and tenderness.
3. Application field: Food industry
Applicable materials: Nuts, fruits, vegetables, flowers, teas, meats, grains, soy products, sea foods, flours, jams, seasoning/condiments, confectioneries, dairy products, snack foods, pastries, additives, soy proteins, encapsulated foods, pig skin, fish maw etc.
Food Microwave Drying (Dehydration, Heating, Tempering, Thawing, Sterilizing, Puffing )
|
Model |
Working Frequency (MHZ) |
Output power (kw) |
Microwave leakage (MW/cm2)
|
External Dimension (m) |
Installation Area (m) |
Gross Weight (Kg) |
Output of Drying (kg/h) |
Output of Sterilization (kg/h) |
HJMD-F-P-15 |
2450±50 |
15 |
≤3 |
7.0x1.1x1.8 |
9.0x3.5x2.5 |
1600 |
40-60 |
150-165 |
HJMD-F-P-20 |
2450±50 |
20 |
≤3 |
8.0x1.1x1.8 |
10x3.5x2.5 |
2000 |
50-120 |
200-250 |
HJMD-F-P-30 |
2450±50 |
30 |
≤3 |
9.0x1.1x1.8 |
11x3.5x2.5 |
2400 |
65-160 |
300-400 |
HJMD-F-P-40 |
2450±50 |
40 |
≤3 |
10x1.1x1.8 |
12x3.5x2.5 |
2800 |
100-240 |
400-500 |
HJMD-F-P-50 |
2450±50 |
50 |
≤3 |
11x1.1x1.8 |
12x3.5x2.5 |
3200 |
120-300 |
500-600 |
HJMD-F-P-80 |
2450±50 |
80 |
≤3 |
14x1.1x1.8 |
15x3.5x2.5 |
5000 |
200-480 |
800-900 |
HJMD-F-P-100 |
2450±50 |
100 |
≤3 |
16x1.1x1.8 |
17x3.5x2.5 |
6000 |
240-600 |
1000-1200 |
|
Working power: 380V, 50Hz; The above specifications for reference only, some will be changed according to your customized demand. | ||||||||
4. The Features of Microwave Tunnel Dryer:
1. Patent core components manufactured by HENGJI, reliable and stable performance.
2. Whole machine chamber are made with 304 stainless steel of food grade, with smooth appearance and easy for cleaning.
3. Interface operation and on-site monitoring, PLC auto-control system, all the datum can be saved, output and printed etc.
4. Working parameters can be setted easily according to different drying demand according to different materials.
5. Microwave power step-less adjustable, conveyor speed adjustable, temperature and humidity are intelligent controlled.
6. Machine start, power off automatically, drying material and microwave generator can start and off synchronously.
7. Adopting Non-contact infrared measuring temperature technology, ensure the accuracy of temperature control easily.
8. Material loading and unloading operated easily, easy for connecting to other process, can achieve automation flow operation easily.
9. HENGJI unique ventilation system can speed up moisture removal speed, raise drying efficiency.
10. Conveyor auto deviation-checking device can keep the machine running smoothly and steadily.
5. The Pictures of Microwave Tunnel Dryer:
Welcome to visit our factory! We will provide you our best
equipments at the reasonable price to meet your requirements.
