HENGJI Model 600~2000 High Capacity Metal Crusher / Waste Cans Crusher

Specifications

HENGJI Model 600~2000 High Capacity Metal Crusher / Waste Cans Crusher
fined output products
Good capacity
Light noise

HENGJI  Model 600~2000 High Capacity  Metal Crusher /   Waste Cans Crusher

1.Description of the Metal  Crusher:

The Metal crusher is newly developed and manufactured scrap metal crushing equipment manufacture by Henan Hengji which is environmentally friendly. It is a new, efficient metal crusher which based on traditional ones and combined domestic and international industrial technology experience to respond to the national "green, low carbon cycle" policy. The crusher is a Metal crusher which developed for small or semi metal pieces. The hammer crusher (hammer mill) crushes by the collisions between high speed hammer and material, and the hammer crusher (hammer mill) has the features of simple structure, high reduction ratio, high efficiency, etc.

2.Operating Principle of Metal Crusher:

In the hammer mill, the motor drives the rotor to rotate at a high speed through the belt, and on the rotor there are series of hammers. When the materials get into the working area of hammers, the rotating hammers with high rotation speed are crushing them, the crushed products meeting the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushing area by the hammers for being recrushed until they reached the required size.

3.Application of Metal Crusher :

  Metal  Crusher is capable of extruding various metal leftover, steel paring, waste copper, aluminum, stainless steel and scrapped car into regular charging as square volume, cylinder etc. different shapes. By this way, the costs of transportation and refining can be reduced. It also makes the transportation easier and faster. This machine mainly used in steel plants, recycling corporation, waste recovery and metal refining industry. Size of compression chamber and bale can be customized.

4.Pictures of of  Metal Crusher :

  5.The crushing process of  Metal Crusher :

raw materials

After crushing



6.Main technical Parameters of  Metal Crusher :

Model	Max Input Size  (mm)	Output Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Diameter (Length×Width×Height) (mm)
600	500×600	10-40	0.5-0.7	18.5	2.2	1720×660×1850
800	700×800	10-50	1-1.2	30	3.6	1910×850×1990
1000	900×1000	14-70	2.5-3	75	6.5	2000×1070×1990
1200	1000×1200	20-60	3-3.5	90	10	2400×1090×2270
1600	1200×1600	20-100	3.5-4.5	112	18	3240×1730×3630
1800	1200×1800	20-120	4.5-5.5	132	24	3620×1910×3870
2000	1200×2000	20-140	5.5-6.5	160	37	4140×2230×4279

 7. Packing and  Delivery :

Packaging Detail:	wooden package
Delivery Detail:	15-20working days after placing the order

8. Service:

1>Pre-sale services: Enthusiasm

We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

2>Sale services: Servant

Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.

3>After-sale services: Faithfulness

To establish long term friendship, we will regularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.

4> We provide one-year warranty to make sure your machine runs consistently. We always offering life long services and provide spare parts for a long term, and repair main parts under right using for free in one year.
