Toilet soap stamping machine/bath soap stamper

Specifications

Toilet soap stamping machine/bath soap stamper
1.whole soap machine line
2.maintenance easily
3.CE cetificate



small solid soap making machine process

soap noodles ( the soap raw material)





Production Flow Chart(capacity:350Kgs/Hour)

Equipments For  Soap Making Production Line
1. Soap mixing machine

Model		S-125
Mixing time:		4-6 minutes
Mixing capacity:		150kgs/time
Mixing Speed:		32r/min
Pressure:		0.4-0.8Mpa
Motor power:		7.5kw
Dimension:		2300*800*1400mm



2. Soap grinding  machine

Model		S260
Diameter of roller:		260mm
Length of roller:		675mm
Power:		7.5kw
Rate of roller speed:		1:03:09
Motor power:		7.5kw
Dimension:		1650×1350×1100mm
Weight:		2318kgs





3.Soap vacuum plodder machine

Model:		XT-500
Capacity:		500kgs/hour
Diameter of screw:		200mm
First speed&Power:		15rpm, 11kw
Second speed&Power:		8-16rpm,7.5kw
Vacuum pump power:		2.2kw
Dimension:		3200*1400*2500mm
Weight:		4000kgs



4.Conveyor

Model:		XD-P04
Capacity:		500-1000kgs/h
Gradient:		≤40°
Motor power:		1.5kw x 4 = 6kw





5.Soap stamper

Model:		XD-120
Capacity:		80-120pcs/min
soap's weight		80g-100g
Motor power:		3kw
Dimension:		1500×950×1300mm
Weight:		1750kgs



6.plastic Packing machine(with date marked)

Model:		SZ320D
Capacity:		50-120pcs/min
Max Packing width:		330mm
Packing Dimension:		L 150-330mm/ W 50-160mm
Motor power:		220V 50/60hz 2.6kw
Weight:		700kgs
Remarks :		optional date labeling device













Deliver time:25 days.

Warranty:One year! If there is any quality problem with our machine during the warranty period, we will offer free parts for customer for fix the machine.

After-sale Service:

a.Technical support online service provided.

b.Technical files service provided.

c.On-site training service provided.

d.Spare parts replacement and repair service provided
