Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Metal Punch Machine for Can Lid Making
Metal Punch Machine for Can Lid Making
US$ 2,500 - 3,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Power Source:
Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Metal Can Lid Making MachineUS$ 10,000 - 20,000MOQ: 1 Set -
Curling MachineUS$ 1,000 - 2,000MOQ: 1 Set
-
Automatic Palletizer Machine/stacker for Empty Tin Can ContainerUS$ 15,000 - 20,000MOQ: 1 Set
-
Automatic Empty Can Palletizer/stacker/tin Can PalletiaerUS$ 15,000 - 20,000MOQ: 1 Set
-
Automatic Empty Cans Palletizer Machine for Food/Beverage Tin CanUS$ 15,000 - 20,000MOQ: 1 Set
Condition
New
CNC or Not
CNC
Power Source
Pneumatic
Place of Origin
Jiangxi, China
Brand Name
Yongxin
Power(W)
4 KW
Weight
3180kg
Dimension(L*W*H)
1600*1180*2310mm
Certification
CE
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Metal punch machine for Can lid making
Specification
| Nominal force | 400KN |
| Nominal stroke | 6mm |
| Slide stroke | 120mm |
| SPM | 55/min |
| Max die height | 220mm |
| Die height adjustment | 80mm |
| Between slide center and frame | 260mm |
| Bolster size | 480*710mm |
| Bolster opening | Φ220*25* Φ 180mm |
| Bolster thickness | 80mm |
| Bed opening | Φ200*150*300mm |
| Slide area | 270*320mm |
| Shank hole | Φ50*70mm |
| Max.inclined angle | 25° |
| Between colums | 300mm |
| Main motor power | 4KW |
| Outline dimension | 1600*1180*2310mm |
| Net weight | 3180kg |
1.Horizonal crankshaft
2.Rigid rotated key dutch
3.Manual die height adjustment with scale display.
Production line
