Home > Products > Chemical can making line > Yongxin 10-20L Chemical Paint Tin Can Making Machine/semi Automatic Chemical Can Making Machine/Seam Welding Coating and Drying
Yongxin 10-20L Chemical Paint Tin Can Making Machine/semi Automatic Chemical Can Making Machine/Seam Welding Coating and Drying
US$ 4,000 - 8,000
/ Set
1 Set(Min. Order)
- ANY PORT IN CHINA
- T/T
You May Like
Product Details
| Application | Chemical, Food | |||
| Packaging Type | Case | Packaging Material | Wood, Wood | |
| Automatic Grade | Automatic | Driven Type | Other, Electric, Electric | |
| Voltage | 380V, 380V | Power | 2.2KW, 2.2KW | |
| Place of Origin | Jiangxi, China | Brand Name | Yongxin | |
| Model Number | Production Line | Dimension(L*W*H) | 1510*1300*1540mm | |
| Weight | 2500KG | Certification | CE Certification | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Yongxin 10-20L chemical paint tin can making machine
| Specification of rolling machine | |
| Model | ZDJY45-450 |
| Diameter range | Φ100-Φ300mm |
| Thickness | 0.25-0.35mm |
| Max width | 400mm |
| Capacity | 30cpm |
| Net weight | 450kg |
| Dimension | 1300*730*1330mm |
| Specification of welding machine | |
| Linear rate of welding | 6-18m/min |
| Production capability | 20~80Cans/min |
| Applicable can diameter | ø65~ø286mm |
| Applicable can height | 70~420mm |
| Applicable material | Tinplate steel-based Temper:T2.5-DR8 |
| Applicable material thickness | 0.18~0.42mm |
| Seam welding landing | 0.4mm 0.6mm 0.8mm 1.2mm |
| Seam point distance | 0.5~0.8mm |
| Applicable copper wire diameter | ø 1.38mm ø 1.5mm |
| Cooling water | Temperature:12-18°C Pressure:0.4~05Mpa Discharge:7L/min |
| Power | 380V±5% 50HZ |
| Total power | 18KVA |
| Dimension | 1200×1100×1800mm |
| Weight | 1200Kg |
| Specification of forming machine | |
Scope of application | big square containers of 9-20L(need change mold) |
Maximum oil pressure | 12Mpa |
Adaptive material thickness | 0.2-0.4mm |
Working air Pressure | 0.3Mpa |
Capacity | 10-15 cans per minute |
Volume of oil tank | 130L |
Power of motor | 7.5kw |
Outline size | 1400*720*1200mm |
Applied electric source | AC380V 50HZ |
Overall Weight | 900kg |
| Specification of flanging machine | |
Model | GT3FB3/3FB4J |
Applicative range | 1L-18L |
Capacity | 30cans/min |
Power | 0.75kw |
Net Weight | 350kg |
Dimension | 680*1020*800mm |
| Specification of sealing machine | |
Model | GT4A19F |
Capacity | 10-17cans/min |
Applicative range | 2-18L square or irregular Can |
Net weight | 750kgs |
Power | 2.2kw |
Dimension | 1070x720x2050mm |
