Welder Machine/Can Body Automatic Seam Welding Machine

Welder Machine/Can Body Automatic Seam Welding Machine thumbnail-1
Welder Machine/Can Body Automatic Seam Welding Machine photo-1
US$ 4,500 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
YONGXIN
Model Number:
FH18-90ZD
Contact Supplier Request Quote Chat Now
Jiujiang Yongxin Can Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/jiujiang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Brand Name YONGXIN
Model Number FH18-90ZD
Voltage 380V
Current 50HZ
Rated Capacity 18KVA
Rated Duty Cycle 18
Dimensions 1300*1100*1800mm
Weight 1800kgs
Usage TIN CAN WELDING
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Welder Machine/Can body automatic seam welding machine

Welder Machine/Can body automatic seam welding machine

Linear rate of welding

6-18m/min

Production capability

20~80Cans/min

Applicable can diameter

ø65~ø286mm

Applicable can height

70~420mm

Applicable material

Tinplate steel-based  Temper:T2.5-DR8

Applicable material thickness

0.18~0.42mm

Seam welding landing

0.4mm  0.6mm 0.8mm  1.2mm

Seam point distance

0.5~0.8mm

Applicable copper wire diameter

ø 1.38mm ø 1.5mm

Cooling water

Temperature:12-18°C Pressure:0.4~05Mpa   Discharge:7L/min

Power

380V±5% 50HZ

Total power

18KVA

Dimension

1200×1100×1800mm

Weight

1200Kg





 Welder Machine/Can body automatic seam welding machine

1), PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.



2), Low voltage apparatus are produced by SCHNEIDER.



3), IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.



4), OMRON is our sensor supplier.



5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan

Welder Machine/Can body automatic seam welding machine





Welder Machine/Can body automatic seam welding machine



Welder Machine/Can body automatic seam welding machine



Welder Machine/Can body automatic seam welding machine

Welder Machine/Can body automatic seam welding machine



Welder Machine/Can body automatic seam welding machineWelder Machine/Can body automatic seam welding machineWelder Machine/Can body automatic seam welding machineWelder Machine/Can body automatic seam welding machineWelder Machine/Can body automatic seam welding machine
