High Speed Fully Automatic cd Cover Making Machine

High Speed Fully Automatic cd Cover Making Machine photo-1
US$ 2,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Food
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/jiujiang
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Chemical, Food
Packaging Type Case
Packaging Material Metal, Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380v
Power 40kw
Place of Origin Jiangxi, China
Brand Name yongxin
Model Number GT-FH18-65ZD
Dimension(L*W*H) 1750*1100*1800mm
Weight 1800kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

High Speed fully automatic cd cover making machine

High Speed fully automatic cd cover making machine



 High Speed fully automatic cd cover making machine





Specification



Linear rate of welding

6-26m/min

Production capability

40~100Cans/min

Applicable can diameter

Φ65~Φ180mm

Applicable can height

60~280mm

Applicable material

Tinplate steel-based

Applicable material thickness

0.2~0.35mm

Seam welding landing

0.4mm 0.6mm

Seam point distance

0.5-0.8mm

Applicable copper wire diameter

Φ 1.38mm Φ 1.5mm

Cooling water

Temperature:15-20°CPressure:0.4~0.5Mpa Discharge:10L/min

Compressed air consumption

600 L/min

Pressure of compressed air

0.5Mpa-0.7Mpa

Power

380V±5% 50HZ

Total power

40KVA

Dimension

1750×1100×1800mm

Weight

1800Kg



 Features



1. PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.

2. Low voltage apparatus are produced by SCHNEIDER.

3. IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.

4. OMRON is our sensor supplier.

5. HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.



Can making technology  process

Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling



Sample can

High Speed fully automatic cd cover making machine





High Speed fully automatic cd cover making machine

High Speed fully automatic cd cover making machine



High Speed fully automatic cd cover making machineHigh Speed fully automatic cd cover making machineHigh Speed fully automatic cd cover making machineHigh Speed fully automatic cd cover making machineHigh Speed fully automatic cd cover making machine
