<KD>Portable Vacuum Pump for Welding
Features
1. The 2XZ series Rotary Vane Vacuum Pump belongs to two stage direct connection structure rotary vane vacuum
pump, which can be used for drying, sealing the container and other ancillary pumping air or net vacuum equipments.
2. It has the advantages of small size, light weight, low noise, convenient for using and more.
3. The 2XZ series Rotary Vane Vacuum Pump can not be used as the compression type delivery pump.
Detailed description
2XZ series rotary vane type vacuum pump can be used independently ,which also can be as Booster pump , Diffusion pump ,Molecular pump and Titanium Pump's pre-pump .Also used as electronic devices produce ,vacuum drying ,filtration ,welding ,metal smelting etc .
Technical data
Model | 2XZ-0.5 | 2XZ-1 | 2XZ-2 | 2XZ-4 | 2XZ-8 | 2XZ-15 | |
Pumping speed (L/S) | 0.5 | 1 | 2 | 4 | 8 | 15 | |
Ult. vacuum (Pa) | Without gas ballast | ≤6×10-2 | |||||
With gas ballast | ≤6.5 | ≤1.33 | |||||
Rotary speed (r/min) | 1400 | 1410 | 1410 | ||||
Working Voltage (V) | 220 | 220/380 | |||||
Motor power (Kw) | 0.18 | 0.25 | 0.37 | 0.55 | 1.1 | 1.5 | |
Inlet diameter (mm) | Φ16 | Φ16 | Φ25 | Φ25 | Φ40 | Φ40 | |
Temp. rise of pump oil (℃) | 40 | ≥45 | ≥65 | ≥70 | |||
Oil capacity (L) | 0.5 | 0.55 | 0.8 | 0.1 | 2.5 | 4.0 | |
Size | L (mm) | 445 | 467 | 488 | 528 | 575 | 703 |
W (mm) | 130 | 130 | 145 | 145 | 172 | 338 | |
H (mm) | 254 | 254 | 280 | 280 | 350 | 453 | |
Weight (kg) (with 3-phase motor) | 13.5 | 15 | 20 | 23 | 48.5 | 77.5 | |
Noise (db) | ≥60 | ||||||
Vibration reference number (u) | ≥80 | ||||||
Packaging:
Service promise:
1. Product quality guarantee is for one year,after our Products the date sold.
2. Products in the quality guarantee period, the company responsible for free maintenance and replacement parts.
3. The user must have the product maintenance with products in product quality guarantee card, certification, and effective bill.
If can not,the date, according to the factory of the date ,will be extended for three months.
Company:
Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd. is specialized in R & D, production, sales, teaching and chemical biology pharmacy equipment integrated company.Company tenet: keeping reputation, valuing contracts, supplying lower prices and better quality equipments to serve the cause of China's scientific research.
the main products are rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), low temperature cooling fluid circulation pump(cool chiller), vacuum drying oven, blast air drying oven, freeze dryer, water/oil bath, magnetic heating stirrer, overhead mixer, ultrasonic cleaning machine, lift platform, etc. Besides,
We are profeddional glass reactor manufactorer, any inquiry is welcomed .Please feel free to contact me if i can help in anything. it is always a pleasure to offer our futture cooperation.
