Function
2017 inovation small pressure reaction vessel china supplier is suitable for flammable, explosive, high toxic, precious media and chemical media of strong penetration to stir.
It is the best no-leak response for petroleum, chemical, organic synthesis, polymer, food and other process to vulcanize, fluorate, oxidize.
Features
♦ Static sealing structure.
♦ The mixer bath electrical machinery transmission uses the magnetic force couple connection.(3)No-touch passing moment, solving the stirred leak problem.
♦ Medium and the stirring member is in sealing state to work.
Technical parameter
Model | CJF- 0.05 | CJF-0.1 | CJF-0.25 | CJF-0.5 | CJF- 1 | CJF- 2 | CJF-3 | CJF-5 | CJF-10 | CJF-20 | CJF-30 |
Capacity(L) | 0.05 | 0.1 | 0.25 | 0.5 | 1 | 2 | 3 | 5 | 10 | 20 | 30 |
Setting Pressure (Mpa) | 22 | ||||||||||
Setting Temperature (℃) | 350 | ||||||||||
Accuracy of temperature control (℃) | ±1 | ||||||||||
Stirring Torque (N.cm) | 120 | ||||||||||
Heating Power (kW) | 0.6 | 0.8 | 1.5 | 2 | 2.5 | 4 | 7 | 10 | 10 | ||
Material | 1Gr18Ni9Ti | ||||||||||
Our Product
Other models
zhengzhou keda Machinery and Instrument Equipment Co., Ltd, established in 1981,is a famous manufacturer of Lab equipment located in the central China. We specialized in rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), cooling chiller, vacuum drying oven, blast drying oven, high-pressure reaction kettle, freeze dryer(lyophilizer), water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle, lift table and so on.
Present, we have become a pacesetter of the lab instrument in China. Our products have been exported to the countries such as the UK, Greece, Poland, US, Australia, Brazil, South Africa, Ghana, Egypt, Iran, Pakistan, Thailand, India, Singapore, Malaysia and so on. Our products are also earning wide recognition among our users.
Though our foreign trade is not for long, we do have a history of more than 30 years for domestic trade. To assure the good quality & good service is our consistent aim.
Service promise
1. Products quality guarantee is for one year, after the product was sold.
2. In the warranty period, the users operate according to instruction but meet problems, our company will maintain free of charge.
3. Beyond the warranty period, products problems can also be solved by my company maintenance, but charge wiring components fees properly.
Technology service
1. We have a mobile repair service team in our company, to carry out maintenance, consulting services in china for many years.
2. Users encounter problems when using our products, please contact us by telephone or email, we will be ready to provide consulting, maintenance and other services immediately.
1. Can the capacity be customized?
Yes.
2. What’s the largest volume you can manufacture?
3000L.
3. What kinds of reactors do you have?
Lifting-FCF series; Non lifting-CJF series,CF series
4. Can you match liner?
Yes,we can supply suitable PTFE and ceramic liners for your models.
5. The maximum pressure and temperature can reach?
Usually 22Mpa, 350 degree C.
6. What’s reactor made from?
Usually SS304 and SS316.
7. What’s your delivery time?
Common model: 3-5 working days
Customized model: 7-15 working days
8. Can you supplycooling function?
Yes.
9. What’s your sealing mode?
Static sealing, no “O” ring.
10. Is there safety valve on your device?
Yes.
