Explosion-proof 30L Jacketed Glass Reactor
Introduction
According to the customer's requirements and standard, we manufacture frequency control speed jacketed glass reactor which has many functions to satisfy kinds of experiments. That is, We innovate to assemble rectification column and create jacketed glass reactor production line.
It is widely used in modern refined chemical, biological pharmacy, new material synthesis industry research experiment, etc. OEM is also welcomed. We have rich experience in OEM.
Performance principle
Double-glazed designed glass reactor, the liner is for reaction solvent, and the jacket for heating or cooling resource(cool liquid,hot water or hot oil), to achieve circulating heating or cooling experiment. And its ancillary equipment-High and low temperature machine which can satisfy functional high & low temp reaction experiments.
Jacketed glass reactor
Technical data
Model |
(EX)S-1L |
(EX)S- 2L |
(EX)S- 3L |
(EX)S- 5L |
(EX)S- 10L |
(EX)S- 20L |
(EX)S- 30L |
(EX)S- 50L |
(EX)S- 100L |
Stirring Power(W ) |
60 |
120 |
180 |
||||||
Stirring Speed(rpm) |
0~600(Max. 1300) |
||||||||
Stirring Shaft Diameter(mm) |
12 |
14 |
16 |
18 |
|||||
Reaction Kettle Capacity(L) |
1 |
2 |
3 |
5 |
10 |
20 |
30 |
50 |
100 |
Power Supply |
220V /50HZ |
||||||||
|
Motor Torque (g/cm) |
2000 |
2400 |
2400 |
4800 |
1000 |
1200 |
1200 |
1500 |
3000 |
Note |
Floor type |
304 all stainless frame |
|||||||
Explosion-proof: 1. The stirring power (W): 180, 250, 370
2. Power supply: 220V / 50HZ or 110V / 60HZ
Features
1. GG17 high-borosilicate glass with nice physical-chemical properties; experiment temperature -100 to 400 degree C; Resistant to strong acidic properties of materials; only touching with glass parts & PTFE, no cross-contamination.
2. Double cylinder; kettle cover is separated from kettle body. It is convenient to disassemble, clean and install.
3. Stirring adopts to mechanical sealing, it keeps higher vacuum degree among the same products in the market. It also keeps high vacuum degree when stirring.
4. Glass(PTFE)discharge valve, non-dead angle mixing, fast emptying, no residue.
5. Frequency control speed gear motor, smooth running,high torque, automatic booster, no spark, noise free, long life.
6. SUS frame and cast aluminum material kettle body support, elegant appearance, stable structure.
7. Circulating water/oil bath, high and low temperature machine can supply heating source;Cooling machine:cooling chiller, high and low temperature machine,convenient and practical
8. Scientific & innovative structure, practical, elegant appearance, domestic industry-leading.
9. Explosion proof is optional.
Packaging
-Wooden case packaging;
-Both neutral and customized packaging can be available.
Shipping
-We can ship the goods to you by International Express such as DHL,TNT,EMS,FedEX and so on and you can also choose the appropriate one based on your timeline and budget. Besides, you can definitely choose to use your own shipping agent.
zhengzhou keda Machinery and Instrument Equipment Co., Ltd, established in 1981,is a famous manufacturer of Lab equipment located in the central China. We specialized in rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), low temperature cooling fluid circulating pump(cool chiller), vacuum drying oven, blast drying oven,high-pressure reaction kettle,freeze dryer(lyophilizer), water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle,lift table and so on.
Present,we have become a pacesetter of the lab instrument in China.Our products have been exported to the countries such as the UK, Greece, Poland, US, Australia, Brazil, South Africa, Ghana, Egypt, Iran, Pakistan, Thailand, India,Singapore, Malaysia and so on.Our products are also earning wide recognition among our users.
Though our foreign trade is not for long, we do have a history of more than 30 years for domestic trade. To assure the good quality & good service is our consistent aim.
Service Promise:
1.Products quality guarantee is for one year,after the product was sold.
2.In the warranty period, the users operate according to instruction but meet problems ,our company will maintain free of charge.
3.Beyond the warranty period ,products problems can also be solved by my company maintenance, but charge wiring components fees properly.
Technology Service:
1.We have a mobile repair service team in our company , to carry out maintenance , consulting services in China for many years.
2.Users encounter problems when using our products , please contact us by telephone or email,we will be ready to provide consulting, maintenance and other services immediately.
CE Certification:
1. What's the max temperature?
Usually the high borosilicate glass can withstand over 300 degree centigrade and the PTFE stirring bar can withstand about 200 degree centigrade
2. What's the size do you have?
We can offer you 1L,2L,5L, 10L, 20L, 30L, 50L, 100L,150L.
3. How many kinds of your glass reactor?
Two types: jacketed glass reactor and single layer glass reactor.
Explosion proof is avaliable.
4. What’s the heating mode of single layer glass reactor?
Oil/water bath heating, and heating mantle
5. Can you offer the supporting facilities?
Yes, we can offer you the vacuum, heating and cooling system as you demand.
