Specifications
Durable&Ecnomic Lab glass reactor(10/20/30/50/80L)1.Good sealing
2.High vacuum degree
3.Efficient condenser
Durable&Ecnomic Lab glass reactor(10/20/30/50/80L)
Function:
1. The reactor with doubled borosilicate glass, the liner can be put in materials, while it stirs under high vacuum.
2. The middle zone can connect the heating source (refrigerating fluid,oil or Electricity hot jacket ), making heating Hydroid or cooling .
3. In the constant temperature conditions , in closed glass container,it can mix and react,under ordinary pressure or suction.At the same time, it is able to control the evaporation of reaction solution as well as backflow.
Feature:
1. GG17 high quality silicon glass owns good chemical-physical attribute.
2. Converting-frequency stir, operating steady; High Torque; no spark
3.PTFE sealing; Patented product; Ultimate vacuum reaches pump vacuum-0.095mpa,better than other ordinary ones;leading dos metic;equipped with the abrasive holding tank.
4. All new stainless steel frame structure (the joints three or four are all stainless steel)
5. the smallest or PTFE no-dead angle bottom discharge value; Customize reactor body and cap based on clients’ different demands.
6. Simple and safe cleaning job without disassembling all accessories after the reaction, not hydrous.
7. Customize all kinds of parts about the whole sets based on clients’ different demands.
Technical Parameter:
Model |
S-10L |
S-20L |
S-30L |
S-50L |
Stirring power(W) |
120 |
180 |
180 |
250 |
Stirring speed(r/mp) |
60~780 |
60~780 |
60~780 |
60~780 |
Motor torque(g/cm) |
10000 |
12000 |
12000 |
15000 |
Reaction flask(L) |
10 |
20 |
30 |
50 |
Discharge way |
Bottom |
PTFE Suck Discharging valve |
||
