Specifications
Plastic Scrap to Heavy Furnace Oil Pyrolysis Plant No Emission Huayin1.safe
2. over 20 years skills
3. DEMO
4. energy-savin
Plastic Scrap to Heavy Furnace Oil Pyrolysis Plant No Emission Huayin
|
Nowadays, natural energy is getting less and less, yet daily rubbish is becoming more and more. Huayin can not produce natural energy, but we can turn trash into energy, which can be used as fuel in many industrial fields. |
The Essence of Hua Yin Group |
|
Over 20 years' experience of inventing, producing, and exporting refinery machines to turn our daily rubbish into fuel oil , diesel, and carbon black, and going through hundreds of experiments to create profit from waste and protect our environment. |
Introduction of main parts and features of pyrolysis plant | |
Reactor |
1. Made by Q345R boiler plate. Also can choose SS310, 310S+Q345R 2. Auto-welding both inside and outside 3. With rock wool insulation board |
Auto-feeder |
1. 50-ton hydraulic pressure to feed about 10 tons in 2hs 2. Can feed all types of materials 3. Both save labor and time |
Catalyst chamber |
1. Improve oil yield 2. Reduce the speed of oil gas so it can be better cooled 3. Clean oil |
Oil-water separator |
1. Separate oil and water 2. Collect heavy oil 3. Water sealing design to keep safe |
Condenser |
1. The oil gas is cooled separately and thoroughly by small pipes inside condensers 2. Light oil is collected here |
Vacuum device |
Keep machine running under normal pressure |
| Main parameters of pyrolysis plant (and oil extraction equipment from used plastic ) | |
Daily capacity |
6/8/10/12 ton |
Reactor material |
Q345R, SS310 |
Thickness of plate |
16mm/18mm |
Accessories material |
Q235R |
Weight |
30-35 ton |
Power |
22KW-25KW |
Space needed |
300 m2 |
Labor needed |
4 |
