1.This machine is suitable for four to open the seam super souvenir sheet of a variety of die production sawing.
2.The chuck with automatic saw blade clamping device can be quickly, effectively clamping the saw blade.
3.On the first card position, the table angle can be flexibility in adjusting the positioning, saw version adaptable.
4.The choice of a large work surface, ground into a mirror surface, with the flotation system, a large format die cutting operation more convenient and flexible.
Specifications
Max.scope of work(mm) | 800 | 1000 | 1200 | 1500 |
Table size (mm) | 600*900 | 700*1000 | 800*1200 | 1000*1300 |
Saw Blade trip (mm) | 30 | 30 | 30 | 30 |
Saw Blade thickness(mm) | 0.3-3 | 0.3-3 | 0.3-3 | 0.3-3 |
Max.thickness(mm) | 40 | 40 | 40 | 40 |
Sheet Category | Wood | Wood | Wood | Wood |
Speed(times/min.) | 1300 | 1300 | 1300 | 1300 |
Total powerW) | 980 | 980 | 980 | 980 |
Voltage (V) | 220/380 | 220/380 | 220/380 | 220/380 |
Model ABC Description:
Type A: pedal with cards, hairdryer dust;
Type B: pedal with cards, Suction dust, air-cushion suspension;
Type C: electrical equipment cards, Suction dust, air-cushion suspension.
