The machine is widely used for curing after UV paint coating surface of screen printing ,phone case, thin film switch, Electronic plastic housing, UV adhesive curing for precision products as motor,callphone speaker ,callphone Battery components ,printer and Computer precision components., UV ink curing for metal and Injection products.
Features
1.Instant dry,time-saving & high efficiency
2. Belt use stepless speed regulation control system
3.High gloss, good friction & solvent resistance can be got after curing
4.The operating current of UV lamp is showed outside so as to control the working status.
5.There is a heat-extraction system to keep a high-efficiency working environment .
6.The speed of conveyor is adjustable,it can be adjusted any reasonable speed you need.
7.There are 2 sets of UV light source system,please use it according to the detailed requirement
8.The imported Teflon mesh belt conveyor, it is enjoying precise production, smooth running , and restful.
Feeding Length |
800 mm |
Feeding Width |
650mm |
Discharging Length |
500 mm |
Feeding Height |
900mm |
Lamp Power |
5.6KW/PC |
Lamp No. |
2PCS |
Transmission Motor |
200W |
Exhaust Fan |
1100W-3 units |
Transmission Speed |
0-32m/min |
Voltage |
380V |
Total Power |
14.7KW |
Overall Dimensions |
L2300*W1000*H1750mm |
