Chip Board Producing Machine/ Spreading Machine

Name: Chip Board Producing Machine/ Spreading Machine
Brand: SG-Machinery
SKU: 141514714
Availability: InStock

US$ 19,999 - 999,999 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

wood-working

Production Capacity:

automatic

Linyi Sengong Machine Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application wood-working

Production Capacity automatic

Place of Origin Shandong, China

Brand Name SG-Machinery

Model Number SG-PL100

Voltage 220/380V

Power(W) 200KW

Certification ISO 9001

Warranty 2 years

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Chip board producting machine
1.Full automatic
2.durable and economic
3.labor-saving
4.certificate: CE/ISO 9001

PICRURES OF PB PRODUCING MACHINE

PB Production Line Discription

1.Chip preparation section	Raw material is reduced into qualified chips by the drum chipper, then the chips are transported to the chip bin, and then feed to the knife-ring flaker by which the chips are turned to flakes, then the flake stored in wet flake bin.
2.Drying and sifting section	The flakes discharged from the wet flake bin are conveyed to the rotary dryer. Qualified core flakes are stored in core flake bin; oversize flakes are send to mill to be re-crushing, and transported to surface flake bin.
3.Glue regulating and applying section	After scaled, the core and surface flakes are to be effectively and uniformly mixed with qualified glue independently in their glue mixers respectively.
4. Forming and hot-pressing section	The surface and core flakes are sent into classi-forming machine, and forming on the mat conveyor uniformly. After processes of metal remover, pre-press, lengthwise saw, cross saw, accelerate conveyor, scaling conveyor, storing conveyor and loading conveyor, mats are transported to carrier and then to hot press. Rough boards after pressing are pushed to unloader via pallet.
5.Cooling and sizing section	The rough board is conveyed to star-cooler for cooling, then the rough board goes through side trimming saw and become a qualified particle-board, stacked on the hydraulic lift
6. Sanding Section	The board are sanded, checked and stored . PLC control is used in mat-forming section
