Product Name: DC-DC step-down constant voltage constant current power supply module dc-dc buck LED driver adjustable step-down power module
Product Type:
Color classification:
Product details:
Module parameters:
Model: CCV3210
Category: synchronous rectified buck constant voltage constant current power supply module
Properties: non-isolated buck module (BUCK) synchronous rectification
Input voltage: 4-35V (limit 35V) Keep the voltage margin. In order to ensure real security module
Output voltage: 1.2-32V adjustable
(Default output 5v)
Default shipping Minimum pressure: 2.5v
Output Current: 0.4-10A long Spontaneous inner heat 6A, temperature does not exceed 60 degrees. At higher ambient temperature deration is required
Working temperature: -40 ~ + 85 degrees
Operating frequency: 150KHZ
Conversion efficiency: up to 96% (efficiency and input and output voltage, current, pressure-related)
Short circuit protection:
Overtemperature protection:
Connection: terminals, free welding, IN is the input, OUT output
Module size: 60 * 26 * 20mm
Weight: about 25-28G
Note:
1, do not reverse, reverse will burn, no warranty,
2, we must control the input voltage is within 35v, not to exceed more than the chip directly burn
3, there is no output backfeed protection diode needed please add yourself
