Woodworking Machine Semi-automatic Finger Joint Cutting Machine

Name: Woodworking Machine Semi-automatic Finger Joint Cutting Machine
Brand: haiyong
Availability: InStock

FOB Price

US$ 1,300 - 2,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Spindle Speed	2840r/min
Max. Working Width	500mm	Place of Origin	Shandong, China
Brand Name	haiyong	Model Number	MX3515A
Power(W)	11kw	Dimension(LWH)	2280X1590x1500mm
Weight	1600kg	Certification	ISO9001
Warranty	One Year	After-sales Service Provided	Engineers available to service machinery overseas

finger joint cutting machine

specification :

Model	MX3515A
ing width	480mm
ing thickness	150mm
working table size	610×850mm
diameter of the Mortising machine	φ50mm
Tenon cutter diameter	φ160mm
Main saw blade size	φ255×φ35.4mm
Scoring saw size	φ180×φ19mm
Mortising shaft speed	6000rpm
The main blade speed	2840rpm
Scriber speed	2840rpm
Coating wheel diameter	φ120mm
Coating wheel speed	58rpm
Mortising shaft power	11kw
Main saw shaft power	2.2kw
Scoring saw power	0.75kw×2
Coated with rubber power	0.2kw
Pump power	4kw
overall size	2280×1590×1500mm
net weight	1600kg
