wide belt sander machine
Specification of the wide belt sander machine
1 The machine adopts welded steel, after quenching,good stability,imported conveyor belt,good reliability,durability.
2 The series uses the beam barrel and the beam seat structure,good stability,convenient maintenance
3 Belt fensioning cylinder adopts coast iron processing,tensile strength is great,good stability,conveyor belt adjusting
4 Cylinder adopts 63x20 cylinder,large power,good stability
5 Active roll stigmas are bold,and after quenching,ensure the stability and durability of the driving roller
6 Thickness display table using photoelectric sensing head,high precision,good stability under complex environment
Technical of the wide belt sanding machine
Model |
R-RP1300 |
R-RP1000 |
R-RP600 |
Working Width |
1300mm |
1000mm |
630mm |
Min.Working Length |
500mm |
500mm |
500mm |
Working Thickness |
3-110mm |
3-110mm |
3-110mm |
Feeding Speed |
6-30m/min |
6-30m/min |
6-30m/min |
Total Power |
63.37kw |
35.25kw |
20.25kw |
Motor Of First Unit |
37kw |
18.5kw |
11kw |
Motor Of Second Unit |
22kw |
15kw |
7.5kw |
Motor Of third Unit |
/ |
/ |
/ |
Feeding Motor |
4kw |
1.5kw |
1.5kw |
Lifting Motor |
00.37kw |
0.25kw |
0.25kw |
Diameter Of First Roller |
240mm |
190mm |
190mm |
Diameter Of Second Roller |
210mm |
190mm |
190mm |
Abrasive Belt Size |
1300x2200mm |
1020* 2200mm |
650*1920mm |
Working Air Pressure |
0.6Mpa |
0.6Mpa |
0.6Mpa |
Volume Of Dust Collector |
9600m3/h |
8000m3/h |
8000m3/h |
Overall Dimensions |
1900 * 1600 * 2100(mm) |
1900 * 1600 * 2100(mm) |
1800*1200*2100mm |
Net Weight |
3300kg |
2200kg |
1200kg |
if you need other model , please feel free to contact me .
