basic information of the plywood production line
the veneer peeling machine is the maain machine in the plywood producing. it can peeling less than Φ 360mm log-core. the same log-core can be changed the space between knife by guide system. it can peel table plate and core plate. it has a high eficiency, and a high rate of wood usage. it is fit for the plywood company for efficient procucing.
technical specifications of plywood production line
Model |
BHX1815 |
BHX1822 |
BHX1827 |
Max cutting length (mm) |
1350 |
2000 |
2600 |
Max cutting diameter (mm) |
Φ400 |
Φ400 |
Φ400 |
Log-core diameter (mm) |
Φ26 |
Φ26 |
Φ26 |
Cutting thickness (mm) |
0.8-3.0 |
0.8-3.0 |
0.8-3.0 |
Veneer output speed (m/min) |
42 |
42 |
42 |
Power (kw) |
19.75 |
21.75 |
25.75 |
Overall dimension (mm) |
3320*1800*1260 |
3700*1800*1490 |
4585*1800*1560 |
N.W (kg) |
3500 |
5500 |
7000 |
