Help CenterHot Press Machine for Plywood
Related Products
Advantage and function of the hot press machinefor plywood
1. can be used in various man-made board, fire prevention board manufacturing and wide application scope, particularly suitable for plywood produuction.
2. the automatic electric apparatus is easy and reable in operation
3. the foundation is simple with low investment.
4 the hot press machine can deal with veneer , membrane , formica, paper.
Technical specification of hot press machine
Model | BY214x8/16(3)H |
Total pressure | 160ton |
Feeding direction | Transversal |
Dimension of hot platen | 2500x1300x42mm |
Number of layers | 3 |
Number of platens | 4 |
Stroke | 300mm |
Diameter & stroke of Oil cylinder | 100mmx 300mm |
Number of cylinders | 8 |
Low pressure pump flux | 63L/min |
High pressure pump flux | 2.5L/min |
Heating medium | Steam or thermal oil |
Frame structure | welded |
Working pressure | 25Mpa |
Total power | 5.5Kw |
Thermal oil furnace motor power | 37.5Kw |
Number of stainless steel plates | 6 |
Overall dimension (Approx) | 3900x1300x2200mm |
Net Weight (Approx) | 8600Kg |
Send Inquiry to This Supplier
