Home > Products > Distillation Plant > Oil refining plant/used oil recycling machinery from JINYUAN
Oil refining plant/used oil recycling machinery from JINYUAN
- 50 Set / Sets per Month
- Lianyungang
- T/T
- Waste Oil Regenerating Equipment for Various Dielectric Oils
- BZ Transformer oil regeneration Equipment
- Transformer OLTC On-load Tap Changer Oil Purifier//separator/Regeneration/Dehydration Machine
- Insulation Oil Regeneration Machine
- On-load Tap Changer Oil Filter Oil Filtration Machine Oil Decanter
- Specilize Model BZ Transformer Oil Regeneration Unit
Product Details
Condition: | New | Flow: | none | Working Pressure: | normal pressure |
Place of Origin: | Henan, China | Brand Name: | Shangqiu Jinyuan Machinery equipment | Model Number: | XY-1 |
Usage: | Transformer Oil | Voltage: | 380v | Power(W): | 10-15kw/h |
Dimension(L*W*H): | 2200mm*6000mm 2500mm*8800mm | Weight: | 25-35 tons | Certification: | CE ISO SGS BV BUV |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Oil refining plant/used oil recycling machinery from JINYUAN
1> Security:
a:Adopting automatic submerged-arc welding technology
b:All of the weldings will be detected by the ultrasonic nondestructive testing method to ensure the welding quality and the welding shape.
c:Adoptingmanufacture process controlling system on the quality, every manufacture process, manufacture date, etc.
d:Equipped with antiexplosion device, safety valves, emergency valves, pressure and temperature meters, as well as the alarming system.
2> Environmental-friendly:
a: Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke
b: Smell during operation: Fully enclosed during the operation
3> Energy conservation and low cost on operation:
special covers of the reactors and chambers can keep hot during the heating in good efficiency as well as the direct heating system to save energy and cost.
NO | ITEM | PROJECT |
1 | Suitable raw materials | Waste engine oil, pyrolysis fuel oil, crude oil |
2 | Structure | Horizontal type |
3 | Capacity(24 hours) | 3.5~6.5 tons |
4 | Work pressure | Normal pressure
|
5 | Oil yield | 85%-95% |
6 | Power | 12KWH |
7 | Cooling method | Cycle water
|
8 | Condensers | 3 pieces of horizontal condensers |
9 | Emission treatment | New de-sulfurization smoke scrubbers
|
10 | Heating method | Hot air
|
11 | Type of installation | With foundation |
12 | Noise dB (A) | Less than 85 |
13 | Dimension of reactor | 2200*6000mm/2500*8800mm |
14 | Operating mode | Semi-continuous operation |
15 | Main chamber weight | 10-13 tons |
16 | Total weight | 25-35 tons |
17 | Installation space required | 35m*15mm |
18 | End product | Non-standard diesel oil |
19 | Manpower | 1~2/shift |
20 | Shipment requirement | 1*40HC+1*40FR |
The whole workflow chart:
Reactor diameter | Container |
2200mm | Two 40’HQ |
More than 2200mm | One 40’FR&one 40’HQ |
introduction of our company:
Shangqiu Jinyuan Machinery Equipment Co., LTD is the first domestic professional institute in the cycling and utilization of waste resources(waste plastic, waste rubber, tyres and waste engine oil), which locates in the intersection of Longhai Line and Beijing-Kowloon Line, Shangqiu, Henan provance.
The advantages of the equipment are Safety, Efficient performance(high oil output and high oil quality), Energy saving, Simple production process and Environment-friently.
Our service aim is For the sake of and satisfying the customers, Developing with the customers.
The people of Jinyuan are increasing innovation and adhering to the spirit of enterprise-good faith and based on the reality.
Our market distribution:
Our certificate:
