Specifications
Used Oil Recycling Machine,Oil Distillation Plant.80%-95% Oil Output
.No pollution
.with CE.SGS.ISO
.more than 6Y lifetime
Used Oil Recycling Machine, Oil Distillation Plant
Advantages:
1> Security:
a:Adopting automatic submerged-arc welding technology
b:All of the weldings will be detected by the ultrasonic nondestructive testing method to ensure the welding quality and the welding shape.
c:Adopting manufacture process controlling system on the quality, every manufacture process, manufacture date,
operators, etc.
d:Equipped with antiexplosion device, safety valves, emergency valves, pressure and temperature meters,as well as the
alarming system.
2> Environmental-friendly:
a: Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke
b: Smell during operation: Fully enclosed during the operation
c: Water pollution: No pollution at all.
3> Energy conservation and low cost on operation: special covers of the reactors and chambers can keep
hot during the heating in good efficiency as well as the direct heating system to save energy and cost.
The Distillation Chamber
The Distillation Column
Condensers
Oil Tank
Smoke Scrubbers
Technology Parameter of Distillation Machine | ||
NO |
ITEM |
PROJECT |
1 |
Suitable raw materials |
Waste engine oil, pyrolysis fuel oil, crude oil |
2 |
Structure |
Horizontal type |
3 |
Capacity(24 hours) |
3.5~6.5 tons |
4 |
Work pressure |
Normal pressure |
5 |
Oil yield |
85%-95% |
6 |
Power |
12KWH |
7 |
Cooling method |
Cycle water |
8 |
Condensers |
4 pieces of vertical condensers |
9 |
Emission treatment |
New de-sulfurization smoke scrubbers |
10 |
Heating method |
Hot air |
11 |
Type of installation |
With foundation |
12 |
Noise dB (A) |
Less than 85 |
13 |
Dimension of reactor |
2200*6000mm/2500*8800mm |
14 |
Operating mode |
Semi-continuous operation |
15 |
Main chamber weight |
10-13 tons |
16 |
Total weight |
25-35 tons |
17 |
Installation space required |
35m*15mm |
18 |
End product |
Non-standard diesel oil |
19 |
Manpower |
1~2/shift |
20 |
Shipment requirement |
1*40HC+1*40FR |
Packing and Shipping
1*40FR and 1*40HC
Weight: about 35tons
/indexen.asp for your reference to check the freight of the transportation
AFTER SALES SERVICE:
1.Quality warranty period: One year warranty for the chamber of the distillation machines,and lifetime maintenance
for complete set of machines. pay the double air tickets, accommodation and food.
2.According to the requirement of the buyer, our company sends engineers for installation and commissioning in
buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.
3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the
buyer.
Successful Installation
About Us
Shangqiu JinYuan Machinery Equipment Co.LTD.,is the first domestic professional institute in the recycling and utilization
of solid wastes (waste plastic,waste tyre,rubber).
Our products include Pyrolysis Plantsfor waste rubber,plastic and tyres,normal or negative pressure. Distillation Plants for
waste engine oil,pyrolysis fuel oil,crude oil and the Carbon Black Deep-process Machines.
We has owned 14 national patents .Our comany also has achieved CE,SGS,ISO,BV,BUV certificates.The emission can
meet GB13271---2001 related standards.
