Hangzhou BANRY Ultrasonic chemical Biodiesel reaction equipment for sale
- 500 Unit / Units per Month
- Shanghai
- T/T
- Side Entry Mixing Equipment
- Small Jacketed Glass Reactor Double Layer Reaction Systems for Laboratory
- Lab Jacketed Glass Reactor 10 Liter Chemical Reactor for Research
- Mini Lab Jacketed Glass Reactor High Borosilicate Reaction Vessel
- Customized Industrial Chemical Reaction Jacketed Glass Reactor
- GG-17 Jacketed Glass Reactor Heating and Cooling Circulator Mixer Reactor
Product Details
Condition: | New | Automatic Grade: | Semi-Automatic | Type: | Other, Biodiesel |
Place of Origin: | Zhejiang, China | Brand Name: | BANRY | Model Number: | BR-28SH/BR-20SH Series |
Voltage: | inquire | Power(W): | 200W-3000W | Dimension(L*W*H): | inquire |
Weight: | inquire | Certification: | CE | Warranty: | 1 Year wannery for a whole set |
After-sales Service Provided: | No overseas service provided |
Product Description
If you want Extracting Application , please skip over the Products Categories :) ↓
♦ Ultrasonic Cutter Ultrasonic Food Cutter Ultrasonic Food Cutting Whole Set Machine Ultrasonic Non-woven Fabric Cutter Ultrasonic Label Cutter Ultrasonic Curtain Fabric Cutter Ultrasonic Rice Bag Fabric Welding and Cutting Ultrasonic Multi-functional Cutter Ultrasonic Rubber Cutter ♦ Ultrasonic New Application Ultrasonic Emulsifier Ultrasonic Herbal Extraction Ultrasonic Homogenizer Ultrasonic Sonocheistry Processor Ultrasonic Spot Welder Ultrasonic MINI welder Ultrasonic Tea Bag Welding and Cutting Ultrasonic Melt Metal Treatment Device Ultrasonic Atomizer Ultrasonic Solder Ironing Equipment Ultrasonic Drilling Equipment for Magnetic Core Ultrasonic MI Cable End Striper Ultrasonic Impact Treatment Device Ultrasonic Transducer for Breaking Kidney Stone ♦ Ultrasonic Parts Ultrasonic Transducer Ultrasonic Oscillator Ultrasonic Generator Ultrasonic Sonotrode ♦ Ultrasonic Analyzer Impedance Analyzer ♦ New Products >>> |
♦ Application field
Suitable for food, cosmetics, paper, paint, chemicals, pharmaceuticals, textiles, fuel thermoelectric, fuel central air conditioning, petroleum, metallurgy, biodiesel and many other industrial processes .
1. Herbal medicine extraction, cells, bacteria, viruses, tissue crushing, such as extraction of cell contents.
2. The material particles dispersed, homogenize, and emulsions. For example, the dispersion of nanometer
materials, cosmetics emulsion.
3. Accelerated dissolution, accelerate chemical reactions, such as chemical synthesis.
♦ Adventage of Biodiesel
BANRY Ultrasonic Biodiesel Reaction is composed of ultrasonic transducer (converter) with cover , booster , horn ( sonotrode , probe ) and generator .
♦ Principle of Ultrasonic Biodiesel Reaction - Acoustic Cavitation
Ultrasonic in the liquid produced hundreds of thousands of times per second, make the liquid to break into tiny bubbles of vibration, these bubbles in the role of the continuous, rapid growth, then suddenly closed, produce the super shock wave, around the bubble produced thousands of atmospheres of pressure and local high temperature, the physical phenomenon known as ultrasonic cavitation effect.
Brand / Product | BANRY / Sonochemistry Processor | |||||
TYPE | BR-28SH | BR-20SH-5 | BR-20SH-10 | BR-20SH-15 | BR-20SH-20 | BR-20SH-30 |
Frequency | 28kHz | 20 kHz | ||||
Max. power | 200W or 500W | 500W | 1000W | 1500W | 2000W | 3000W |
Handing Capacity (L/h) | ≤500 | ≤500 | ≤800 | 200-1000 | 300-1600 | 1600-2500 |
Apply | laboratory | Production line , can be used in combination | ||||
Allow pressure | Max≥5 MPa | |||||
Allow temperature | Max≥350°c | |||||
Generator | Digital generator can be adjusted the output amplitude from 50% to 100%, frequency tracking automatically to sure working continuously | |||||
Cable | Standard 5m Special length, please inform us |
BANRY Ultrasonic 's processing cycle = Traditional way's processing cycle / 20
Hangzhou Banry Ultrasonic Focus on the domestic first high-power ultrasonic probe ultrasonic sonochemistry processing equipment. Does not change a customer's existing production equipment and technological process, through a simple installation can be your ordinary equipment upgrades for the chemical industry with the advanced ultrasound equipment. Ultrasonic high-power, and low investment, simple installation, output and efficiency was improved.
Ultrasonic technology has a prominent advantages, that is, it does not have moving parts, there is no electromagnetic radiation, is simple to install fixed, in particular for the high-pressure high-temperature, toxic, explosive or dangerous environment for the application.
1. Optional frequency and power, 40kHz — 20 kHz , 200W - 3000W .
2. Withover current , overvoltage protection ,to ensuresystem security .
3. Frequency automatic tracking adjustment , to avoid the load impedance with the ambient temperature , the working medium due to factors such as changes in the larger power fluctuations.
4. Constant power , good effect .
5. Ultrasonic digital generator , small size , light weight and high efficiency .
6. Reasonable structure , easy ventilation , continuous running and reliable operation.
Modular design , can be by several hundred watts or several kilowatts of power to form tens kilowatts generator , which can optimize the combination of the transducer, and then ensure transducer work in the best condition; such as a generator fails, the other unitstill work , easy to repair the damaged unit .
♦ After-sale Service
Please click the following pictures to see your interesting products details :
Hangzhou BANRY Ultrasonic chemical Biodiesel reaction equipment for sale
