1. To Confirm the Product Application Field ( Please click on the corresponding text. )
|
◊ Ultrasonic Cutting Equipment ◊ Ultrasonic Sonochemistry System Ultrasonic Food Cutter Ultrasonic Dispersion Equipment Ultrasonic Window Blind Fabric Cutter Ultrasonic Emulsifier Ultrasonic Non-woven Fabrics Cutter Ultrasonic Herbal Extraction Equipment Ultrasonic Handheld Label Fabric Ultrasonic Cutter Ultrasonic Sonochemistry Processor Ultrasonic Plastic Woven Rice Fabrics Bag Cutter Ultrasonic Homogenizer Ultrasonic Rubber Cutter
◊ Ultrasonic Welder ◊ Ultrasonic Metal Treatment Device Ultrasonic Tea Bag Sealing And Cutting Device High-power Ultrasonic Metal Melt Treatment Device Mini ultrasonic spot welder Ultrasonic IC Card Welding Device Ultrasonic Handle spot Welder
◊ Ultrasonic Atomizer ◊ Ultrasonic Seamless Sewing Part Ultrasonic Atomizer Ultrasonic Seamless Sewing Module
◊ Ultrasnic MI Cable End Stripper ◊ Ultrasonic Impact Treatment Device Ultrasnic MI Cable End Stripper Ultrasonic Ageing Treatment System
◊ Ultrasonic Medical Application ◊ Ultrasonic Parts Ultrasonic Transducer for Breaking The Kidney Stones Ultrasonic Transducer Ultrasonic Oscillator Digital Control Qenerator Analog Qenerator ◊ Ultrasonic Measuring Meter Impedance Analyzer Ultrasonic amplitude measuring meter Ultrasonic power(sound intensity) measuring meter |
2. If you want Extraction application , following please :) ↓
♦ Application field
Suitable for food, cosmetics, paper, paint, chemicals, pharmaceuticals, textiles, fuel thermoelectric, fuel central air conditioning, petroleum, metallurgy, bio-diesel and many other industrial processes .
1. Herbal medicine extraction, cells, bacteria, viruses, tissue crushing, such as extraction of cell contents.
2. The material particles dispersed, homogenize, and emulsions. For example, the dispersion of nanometer
materials, cosmetics emulsion.
3. Accelerated dissolution, accelerate chemical reactions, such as chemical synthesis.
BANRY Ultrasonic Extraction is composed of ultrasonic transducer (converter) with cover , booster , horn ( sonotrode , probe ) and generator .
♦ Definition of Ultrasonic Extraction
Ultrasonic Extraction is the use of ultrasound (frequency> 20KHz) with the mechanical effect, cavitations effect and thermal effect, by increasing the movement velocity of the molecular medium, increasing media penetration in order to extract material (herbal medicine) active ingredient technology.
♦ Principle of Ultrasonic Extraction - Acoustic Cavitation
Ultrasonic in the liquid produced hundreds of thousands of times per second, make the liquid to break into tiny bubbles of vibration, these bubbles in the role of the continuous, rapid growth, then suddenly closed, produce the super shock wave, around the bubble produced thousands of atmospheres of pressure and local high temperature, the physical phenomenon known as ultrasonic cavitation effect.
| TYPE | BR-28SH | BR-20SH-5 | BR-20SH-10 | BR-20SH-15 | BR-20SH-20 | BR-20SH-30 |
| Frequency | 28kHz | 20 kHz |
||||
| Max. power | 200W or 500W | 500W | 1000W | 1500W | 2000W | 3000W |
| Handing Capacity (L/h) | ≤500 | ≤500 | ≤800 | 200-1000 | 300-1600 | 1600-2500 |
| Apply | laboratory | Production line , can be used in combination | ||||
| Allow pressure | Max≥5 MPa | |||||
| Allow temperature | Max≥350°c | |||||
| Generator | Digital generator can be adjusted the output amplitude from 50% to 100%, frequency tracking automatically to sure working continuously | |||||
| Cable |
Standard 5m Special length, please inform us |
|||||
1. High extraction efficiency
The unique physical characteristics of ultrasound can induce plant cell tissue broken or deformed, so that extraction is more fully of herbal medicine active ingredients, the extraction rate increased significantly than traditional craft of 50 to 500%;
2. Short extraction time
Ultrasonic extraction of herbal medicine can usually in 24-40 minutes to get the best extraction rate, extraction time greatly reduce the 2 / 3 than traditional methods, medicinal raw materials large processing capacity;
3. Low extraction temperature
Ultrasonic extraction best temperature of herbal medicine is 0-60 ℃, for the case of heat-labile, susceptible to hydrolysis or oxidation of the active ingredients in medicinal herbs has a protective effect, while significantly saving energy; extraction temperature 40 - 60 ℃, to protect the active ingredient.
4. Wide Adaptability
Ultrasonic extraction of herbal medicines is not limit of component polarity and molecular size, suitable for extracting various herbs and components;
5. Extract liquid little impurities, the active ingredient is easy to separate and purify;
6. Extraction of low operating costs, overall economic efficiency significantly;
7. Simple operation, easy to maintenance.
BANRY Ultrasonic vegetable herbal processor
