If you want Hard Materials Cutting Application,please skip over the Products Categories↓
|
♦ Ultrasonic Cutter Ultrasonic Food Cutter Ultrasonic Food Cutting Whole Set Machine Ultrasonic Non-woven Fabric Cutter Ultrasonic Label Cutter Ultrasonic Curtain Fabric Cutter Ultrasonic Rice Bag Fabric Welding and Cutting Ultrasonic Multi-functional Cutter Ultrasonic Rubber Cutter ♦ Ultrasonic New Application Ultrasonic Emulsifier Ultrasonic Herbal Extraction Ultrasonic Homogenizer Ultrasonic Sonocheistry Processor Ultrasonic Spot Welder Ultrasonic MINI welder Ultrasonic Tea Bag Welding and Cutting Ultrasonic Melt Metal Treatment Device Ultrasonic Atomizer Ultrasonic Solder Ironing Equipment Ultrasonic Drilling Equipment for Magnetic Core Ultrasonic MI Cable End Striper Ultrasonic Impact Treatment Device Ultrasonic Transducer for Breaking Kidney Stone ♦ Ultrasonic Parts Ultrasonic Transducer Ultrasonic Oscillator Ultrasonic Generator Ultrasonic Sonotrode ♦ Ultrasonic Analyzer Impedance Analyzer ♦ New Products >>> |
♦ Application field
BANRY 28KHz BR-28C2 Multi-functional Ultrasonic Cutting Machine ( Cutter ) is specially for cutting :
1. Thermal plastic ( Plate , sheet , film , laminated material ) ;
2. Carbon fiber ( CFRP ) ;
3. Rubber ( Vulcanized latex , non-vulcanized latex , sheeting materials, tube ) ;
4. Composite materials [( polyethylene fiber , molded articles containing carbon or glass fiber ( GFRP ) ] ;
5. Resin ( ABS ) ;
6. Silicone ;
7. Food ;
8. Foam ;
9. Paper ( Honeycomb paper ) ;
10. PVC foam board .
Ultrasonic cutter not only can be used by handle ( Suitable for few material of temporary cutting ) , but also can be used to on robot arm ( Suitable for mass cutting on production line ) .
♦ Quality Assurance and After-sale Service
BANRY Ultrasonic 28KHz BR-28C2 Multi-function cutter is composed of ultrasonic transducer ( converter ) , cover , horn , knife and generator.
♦ Principle of Ultrasonic Hard Materials Cutting
Ultrasonic energy to the vibration of ten million times , cutting and gluing the cutting edge at the same time , so the cutting point will not rough selvedge or fraying like conventional cutting , cutting edge will very smoothly . So it can process all kinds of materials which are hard to cut through ordinary knifes .
Brand / Product |
BANRY / Multi-function Hard Materials Cutter |
Model |
BR-28C2 |
Frequency |
28kHZ |
Cutting Materials |
1. Thermal plastic ( Plate , sheet , film , laminated material ) ; 2. Carbon fiber ( CFRP ) ; 3. Rubber ( Vulcanized latex , non-vulcanized latex , sheeting materials, tube ) ; 4. Composite materials [( polyethylene fiber , molded articles containing carbon or glass fiber ( GFRP ) ] ; 5. Resin ( ABS ) ; 6. Silicone ; 7. Food ; 8. Foam ; 9. Paper ( Honeycomb paper ) ; 10. PVC foam board . and so on. |
| Cutting Thickness |
1cm-20cm (Normal: 1cm , other size : please contact us for customization) |
Cutting Power |
200W |
Switch |
Foot Switch or External Control |
N.W |
4KGS |
Generator |
analog generator |
Cable |
Standard 2m Special length, please inform us |
♦ Advantage
1. Good smooth cutting edge ;
2. The cuting efficiency is 10 times more than traditional ways , cost savings ;
3. Adopt compressed air to sure working stably for a long time ;
4. Special replaceable knife ( Wear-resistant ) , cost savings ;
5. Simple operation, handle cutting or used for robot arm .
Please click the following pictures to see your interesting products details :
CNC Robot Arm Connection muti-function knife Ultrasonic foam cutting machine 28k multi-functional hand-held hard carbon fiber ultrasonic cutter e
