Sand drying equipent, silica sand dryer, quartz sand production line
Sand production line:
Sand making machine------sand washing machine------sand dryer-------vibrating screen
Introduction of silica sand dryer:
silica sand dryer is a machine that is able to process large quantities of materials and the advantages include reliable operation, elastic running principle, strong adaptability and big processing capacity. Sand dryer is generally suitable for drying granular materials and has good drying effect especially when drying sand, river sand and quartz sand in building material, chemistry and casting industry.
silica sand dryer structure:
1.Cylinder 2.Front rolling ring 3.Back rolling ring 4.gear 5.Roller 6.drag roll 7.small gear 8.discharging part 9.lifting board 10.Reducer 11.motor 12.hot wind tube 13.feeding chute 14.Furnace body
Note: According to user need to design coal gas generator, burner or elevator, belt conveyor, quantitative feeder, cyclone dust collector,
silica sand dryer drying Process:
Belt conveyor------ Hot blast pipe------Rotary dryer----Discharging box-------Dust collector------Belt conveyor------Air blower------pool
Silica Sand dryer technical parameter:
|
Model(D*L)(mm) |
HZG800*8000 |
HZG1000*10000 |
HZG1200*12000 |
HZG1500*15000 |
|
Volume |
4-5m³ |
7.82m³ |
13.75 m³ |
24.9 m³ |
|
Rotate speed |
4-9r/min |
3-7 r/min |
3-7 r/min |
3-7 r/min |
Tilt |
3-5° |
3-5° |
3-5° |
3-5° |
Motor model |
Y132M2-6 |
Y132M2-6 |
Y160M-6 |
Y180L-6 |
Power |
3kw |
4 kw |
7.5kw |
15kw |
Reducer model |
JZQ 350 |
JZQ 400 |
JZQ 500 |
JZQ650 |
Weight |
2.2t |
7.5t |
10.3t |
18.33t |
Heating source of silica sand dryer:
You can use coal, natural gas, electricity, oil, biomasss, LPG and wind power to heat the dryer machine.
Materials that can be dried by silica sand dryer:
Applications:sand dryer used for drying silica sand, mortar, cement slag, clay, coal gangue,fly ash, gypsum, iron, limestone and other raw materials, widely used in building materials, chemical, foundry and other industries .
Brief Description: Mainly used for fly ash, slag, sand, coal, iron, ore, blue carbon and other materials drying.
Silica sand dryer shipping:
In order to help you to recommend suitable silica sand dryer, can you tell me the following information in your inquiry?
1. What is the material you want to dry?
2. What is the moisture of the feed materials?
3. What is the final moisture you want to get?
4.What is the hear source?(firewood, coal, heat gas or electricity)
4. What is the production capacity per hour or per day?
Our main drying equipment machinery:Sand dryer, manure dryer, coal dryer, gypsum dryer, etc.
How to visit us ?
If you want to visit our factory, please note our city name, Zhengzhou City, Henan Province, China(mainland)
Our air port name is : Zhengzhou Xinzheng International air port.
Train station name is: Zhengzhou (Zhengzhou north) train station
If you have anything unclear, please let me know, i will reply you in 24 hours!
